Audi A8 D5 (2017-2022) driver front air bag crash sensor Wiring diagram
This page shows the only wiring diagram for the component.driver front air bag crash sensor, which is found in the car Audi A8 D5 (2017-2022). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram driver front air bag crash sensor (1 of 1)
BLK WIRE
BLU WIRE
BLU/VIO WIRE
BRN WIRE
CENTER CRASH SENSOR FOR X/Y AXIS
COMPUTER DATA LINES SYSTEM
DRIVER BELT FORCE LIMITER
DRIVER FRONT AIR BAG CRASH SENSOR
DRIVER SEAT BELT TENSIONER IGNITER 1
DRIVER THORAX AIR BAG CRASH SENSOR
FRONT PASSENGER BELT FORCE LIMITER
FRONT PASSENGER SEAT BELT TENSIONER IGNITER 1
FRONT PASSENGER THORAX AIR BAG CRASH SENSOR
FUSE 10
FUSE 16
FUSE PANEL H
FUSE PANEL M
GRN/BLU WIRE
GRN/VIO WIRE
GRY WIRE
GRY/BLU WIRE
HOT AT ALL TIMES
LEFT FRONT DOOR COUPLING POINT
LEFT FRONT SEAT BELT
LEFT FRONT SEAT BELT TENSIONER CONTROL MODULE
ORG/ WIRE
ORG/BRN WIRE
PASSENGER SIDE FRONT AIR BAG CRASH SENSOR
RED WIRE
RED/GRN WIRE
RIGHT FRONT DOOR COUPLING POINT
RIGHT FRONT SEAT BELT
RIGHT FRONT SEAT BELT TENSIONER CONTROL MODULE
VIO WIRE
WHT WIRE
WHT/RED WIRE
YEL WIRE
Go to component -> Supplemental restraints circuit (4 of 7) -> DRIVER FRONT AIR BAG CRASH SENSOR
