Audi A8 D5 (2017-2022) driver ambient lighting fiber optic cable Wiring diagrams
This page contains all the electrical diagrams for the component. driver ambient lighting fiber optic cable, in which he is found in the car Audi A8 D5 (2017-2022). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram driver ambient lighting fiber optic cable (1 of 2)
BLK/VIO WIRE
BLK/YEL WIRE
BLU WIRE
BLU/RED WIRE
BRN WIRE
DRIVER AMBIENT LIGHTING FIBER OPTIC CABLE
DRIVER SEAT BACKREST COUPLING POINT
DRIVER SIDE REAR DOOR CONTACT SWITCH
DRIVER SIDE REAR DOOR LOCK UNIT
DRIVER SIDE REAR EXTERIOR DOOR HANDLE ILLUMINATION LAMP
DRIVER SIDE REAR SILL PANEL STRIP AMBIENT LIGHTING LAMP
FRONT DRIVER SEAT COUPLING POINT
FRONT PASSENGER AMBIENT LIGHTING FIBER OPTIC CABLE
FRONT PASSENGER SEAT BACKREST COUPLING POINT
FRONT PASSENGER SEAT COUPLING POINT
FUSE 2
FUSE 6
FUSE PANEL C
GRN/BLK WIRE
GRY WIRE
HOT AT ALL TIMES
LEFT REAR DOOR COUPLING POINT
PASSENGER SIDE REAR DOOR CONTACT SWITCH
PASSENGER SIDE REAR DOOR LOCK UNIT
PASSENGER SIDE REAR EXTERIOR DOOR HANDLE ILLUMINATION LAMP
PASSENGER SIDE REAR SILL PANEL STRIP AMBIENT LIGHTING LAMP
RED WIRE
RED/GRY WIRE
RED/WHT WIRE
RIGHT REAR DOOR COUPLING POINT
VIO WIRE
VIO/GRN WIRE
VIO/GRY WIRE
W/ AMBIENT LIGHTING
W/O SEAT VENTILATION W/ SEAT VENTILATION
WHT WIRE
WHT/BRN WIRE
Go to component -> Courtesy lamps circuit (9 of 10) -> DRIVER AMBIENT LIGHTING FIBER OPTIC CABLE
Wiring diagram driver ambient lighting fiber optic cable (2 of 2)
AUTOMATIC TRANSMISSION COUPLING POINT
BRN WIRE
BRN/WHT WIRE
BRN/YEL WIRE
COUPLING POINT IN LEFT REAR SEAT
DRIVER ACTIVE HEAD RESTRAINT IGNITER
DRIVER AMBIENT LIGHTING FIBER OPTIC CABLE
DRIVER ASSISTANCE SYSTEMS CONTROL MODULE
DRIVER SEAT ADJUSTMENT CONTROL HEAD
DRIVER SEAT BACKREST BLOWER FAN
DRIVER SEAT BACKREST COUPLING POINT
DRIVER SEAT BELT SWITCH
DRIVER SEAT COUPLING POINT
DRIVER SEAT CUSHION BLOWER FAN
DRIVER SEAT LUMBAR SUPPORT ADJUSTMENT SWITCH
DRIVER SIDE FRONT CENTER AIR BAG IGNITER OCCUPANT CONTACT PROTECTION
DRIVER SIDE REAR SIDE SILL PANEL STRIP AMBIENT LIGHTING LAMP
DRIVER SIDE REAR THORAX AIR BAG IGNITER
DRIVER SIDE SECOND ROW SEAT BELT SWITCH
DRIVER SIDE SILL PANEL STRIP AMBIENT LIGHTING LAMP
DRIVER THORAX AIR BAG IGNITER
HEATING ELEMENT CONTROL MODULE 1
LEFT FOOTWELL LAMP
LEFT FRONT SEAT COUPLING STATION
LEFT REAR AIR VENT ILLUMINATION BULB
LEFT REAR BACKREST HEATING ELEMENT
LEFT REAR BENCH SEAT HEATING ELEMENT
LEFT REAR INFORMATION DISPLAY CONTROL HEAD CONTROL MODULE
LEFT REAR SEAT COUPLING STATION
MEMORY SEAT/STEERING COLUMN ADJUSTMENT CONTROL MODULE
TO LEFT REAR DOOR COUPLING POINT (DIAGRAM 8 OF 12)
TRANSMISSION CONTROL MODULE
TRANSMISSION FLUID COOLER COUPLING POINT
W/ AMBIENT LIGHTING
W/ AUXILIARY LAMPS
W/O SEAT VENTILATION W/ SEAT VENTILATION
WHT WIRE
WHT/BRN WIRE
Go to component -> Ground distribution circuit (7 of 12) -> DRIVER AMBIENT LIGHTING FIBER OPTIC CABLE
