Audi A8 D5 (2017-2022) cylinder block coolant valve Wiring diagram

BLK WIRE BLK/BLU WIRE BLK/GRN WIRE BLK/VIO WIRE BLU WIRE BLU/WHT WIRE BRN WIRE BRN/RED WIRE CYLINDER BLOCK COOLANT VALVE ENGINE COUPLING POINT 2 GRN WIRE GRN/BLU WIRE GRN/WHT WIRE GRY/BLU WIRE GRY/WHT WIRE IGNITION COIL 4 W/ POWER OUTPUT STAGE IGNITION COIL 5 W/ POWER OUTPUT STAGE IGNITION COIL 6 W/ POWER OUTPUT STAGE LEFT COUPLING POINT IN ENGINE/MOTOR COMPARTMENT MECHANICAL COOLANT PUMP SWITCH VALVE NCA WIRE OIL LEVEL THERMAL SENSOR PISTON COOLING NOZZLE CONTROL VALVE RED/BLK WIRE RED/GRY WIRE RED/WHT WIRE TO SPARK PLUG 4 TO SPARK PLUG 5 TO SPARK PLUG 6 VIO WIRE VIO/RED WIRE WHT WIRE WHT/BLU WIRE WHT/GRN WIRE WHT/GRY WIRE WHT/RED WIRE WHT/VIO WIRE WHT/YEL WIRE YEL/BLU WIRE YEL/GRN WIRE YEL/RED WIRE
