Audi A8 D5 (2017-2022) automatic interior light switch button Wiring diagram
This page shows the only wiring diagram for the component.automatic interior light switch button, which is found in the car Audi A8 D5 (2017-2022). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram automatic interior light switch button (1 of 1)
AUTOMATIC INTERIOR LIGHT SWITCH BUTTON
BLK/VIO WIRE
BLU WIRE
BLU/GRY WIRE
BLU/WHT WIRE
BRN WIRE
EMERGENCY CALL BUTTON
FRONT INTERIOR LAMP BUTTON
FRONT PASSENGER AIR BAG DISABLED INDICATOR LAMP
GRN/BLK WIRE
LEFT AMBIENT ROOF LAMP
LEFT FRONT READING LAMP
LEFT FRONT READING LAMP BUTTON
LEFT REAR DOOR COUPLING POINT
LEFT REAR READING LAMP
LEFT REAR READING LAMP SWITCH
REAR INTERIOR LAMP
REAR READING LAMP FRONT BUTTON
RED/BLK WIRE
RED/GRY WIRE
RED/WHT WIRE
RIGHT AMBIENT ROOF LAMP
RIGHT FRONT READING LAMP
RIGHT FRONT READING LAMP BUTTON
RIGHT REAR READING LAMP
RIGHT REAR READING LAMP SWITCH
ROAD SIDE ASSISTANCE BUTTON
ROOF ELECTRONICS CONTROL MODULE
ROOF SHADE BUTTON 1
SUNROOF BUTTON
VIO/BLU WIRE
VIO/GRN WIRE
VIO/RED WIRE
YEL/RED WIRE
Go to component -> Courtesy lamps circuit (6 of 10) -> AUTOMATIC INTERIOR LIGHT SWITCH BUTTON
