Electronic suspension circuit for Audi A8 D4 (2010-2014)

BLK WIRE BLK/GRN WIRE BLU WIRE BLU/RED WIRE BLU/WHT WIRE BRN WIRE BRN/GRN WIRE FUSE 3 FUSE 5 FUSE CARRIER 1 FUSE CARRIER 4 FUSE PANEL F (RIGHT FRONT LUGGAGE COMPT) GRN WIRE GRN/BLK WIRE GRN/BLU WIRE GRN/GRY WIRE GRN/YEL WIRE GRY WIRE GRY/RED WIRE HOT AT ALL TIMES HOT W/ POWER SUPPLY RELAY (TERMINAL 15) ENERGIZED LEFT FRONT DAMPING ADJUSTMENT VALVE LEFT FRONT LEVEL CONTROL SYSTEM SENSOR (AT LEFT SIDE OF FRONT AXLE) LEFT REAR DAMPING ADJUSTMENT VALVE LEFT REAR LEVEL CONTROL SYSTEM SENSOR (AT LEFT SIDE OF REAR AXLE) LEVEL CONTROL SYSTEM CONTROL MODULE (RIGHT SIDE OF LUGGAGE COMPT) RED WIRE RED/BLK WIRE RED/BLU WIRE RED/GRY WIRE RED/YEL WIRE RIGHT FRONT DAMPING ADJUSTMENT VALVE RIGHT FRONT LEVEL CONTROL SYSTEM SENSOR (AT RIGHT SIDE OF FRONT AXLE) RIGHT REAR DAMPING ADJUSTMENT VALVE RIGHT REAR LEVEL CONTROL SYSTEM SENSOR (AT RIGHT SIDE OF REAR AXLE) WHT WIRE WHT/BLK WIRE WHT/BLU WIRE WHT/GRY WIRE WHT/RED WIRE WHT/YEL WIRE YEL/BLU WIRE

1 2 3 4 5 6 PNK WIRE BLK/GRN WIRE BRN WIRE BRN/GRN WIRE COMPUTER DATA LINES SYSTEM GRN WIRE GRN/BRN WIRE GRN/WHT WIRE GRN/YEL WIRE GRY WIRE GRY/YEL WIRE HOT AT ALL TIMES LEFT FRONT SUSPENSION STRUT VALVE LEFT REAR SUSPENSION STRUT VALVE LEVEL CONTROL ACCUMULATOR VALVE LEVEL CONTROL PRESSURE SENSOR LEVEL CONTROL PUMP TEMPERATURE SENSOR LEVEL CONTROL SYSTEM COMPRESSOR MOTOR LEVEL CONTROL SYSTEM CONTROL MODULE (RIGHT SIDE OF LUGGAGE COMPT) PNK WIRE RED/GRY WIRE RED/WHT WIRE RIGHT FRONT SUSPENSION STRUT VALVE RIGHT REAR SUSPENSION STRUT VALVE SELF-LEVELING SUSPENSION FUSE VALVE BODY WHT/BLK WIRE WHT/BRN WIRE WHT/RED WIRE YEL/BLK WIRE YEL/BLU WIRE
