Audi A8 D4 (2010-2014) telephone baseplate Wiring diagram
This page shows the only wiring diagram for the component.telephone baseplate, which is found in the car Audi A8 D4 (2010-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram telephone baseplate (1 of 1)
12 V SOCKET 3
12 V SOCKET SOCKET 2
12-PIN CONNECTOR
BLK WIRE
BLU WIRE
BRN WIRE
CIGARETTE LIGHTER
COMFORT SYSTEM CENTRAL CONTROL MODULE
COMFORT SYSTEM CENTRAL CONTROL MODULE 2
CONVERTER W/ SOCKET,
COOLER
DATA BUS ON BOARD DIAGNOSTIC INTERFACE
ELECTROMECHANICAL PARKING BRAKE CONTROL MODULE
FROM FUSE PANEL F (DIAGRAM 5 OF 8)
FROM FUSE PANEL F (DIAGRAM 7 OF 8)
FROM SAFETY FUSE ASSEMBLY (DIAGRAM 1 OF 8)
FUEL PUMP RELAY
FUSE 10
FUSE 11
FUSE 12
FUSE 13
FUSE 14
FUSE 15
FUSE 16
FUSE 2 FUSE 3
FUSE 4
FUSE 5
FUSE 6
FUSE 7
FUSE 8
FUSE 9
FUSE CARRIER 3
FUSE CARRIER 4
FUSE PANEL F
GRN WIRE
GRY WIRE
LEVEL (UNDER SYSTEM REAR CONTROL CENTER MODULE CONSOLE)
NCA WIRE
REAR CIGARETTE LIGHTER
REAR TELEPHONE CHARGING STATION
RED WIRE
SELECTOR LEVER SENSOR SYSTEM CONTROL MODULE
SOCKETS RELAY (IN RELAY & FUSE CARRIER, RIGHT SIDE OF LUGGAGE COMPT)
TELEPHONE BASEPLATE
VIO WIRE
YEL WIRE
Go to component: -> Power distribution circuit (6 of 8) -> TELEPHONE BASEPLATE
