Audi A8 D4 (2010-2014) roof electronics control module (in front Wiring diagram
This page shows the only wiring diagram for the component.roof electronics control module (in front, which is found in the car Audi A8 D4 (2010-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram roof electronics control module (in front (1 of 1)
BLK WIRE
BLU WIRE
BRN WIRE
BRN/BLU WIRE
BRN/GRN WIRE
BRN/YEL WIRE
COMPUTER DATA LINES SYSTEM
DRIVER'S DOOR WARNING LAMP (W/ AUXILIARY LAMPS)
FRONT INTERIOR LAMP
FRONT INTERIOR LAMP BUTTON
FRONT PASSENGER'S DOOR CENTRAL LOCKING LOCK UNIT
FRONT PASSENGER'S DOOR WARNING LAMP (W/ AUXILIARY LAMPS)
FUSE FUSE CARRIER
FUSE PANEL C (LEFT END OF DASH)
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT AT ALL TIMES FUSE PANEL B (RIGHT END OF DASH) FUSE FUSE CARRIER
INSTRUMENT ILLUMINATION CIRCUIT
INTERIOR LIGHT)
LEFT AMBIENT ROOF LAMP
LEFT FRONT ENTRY LAMP
LEFT FRONT READING LAMP
LEFT FRONT READING LAMP BUTTON
LEFT REAR READING LAMP 2 (W/ AUXILIARY LAMPS)
LEFT REAR READING LAMP SWITCH
ORG/BRN WIRE
ORG/GRN WIRE
REAR READING LAMP FRONT BUTTON
RED/WHT WIRE
RIGHT AMBIENT ROOF LAMP
RIGHT FRONT ENTRY LIGHT
RIGHT FRONT READING LAMP
RIGHT FRONT READING LAMP BUTTON
RIGHT REAR READING LAMP 2 (W/ AUXILIARY LAMPS)
RIGHT REAR READING LAMP SWITCH 1
ROAD SIDE ASSISTANCE BUTTON
ROOF ELECTRONICS CONTROL MODULE (IN FRONT
VIO WIRE
W/ AUXILIARY LAMPS
WHT WIRE
YEL WIRE
Go to component: -> Courtesy lamp circuit (2 of 3) -> ROOF ELECTRONICS CONTROL MODULE (IN FRONT
