Audi A8 D4 (2010-2014) rear window shade switch Wiring diagrams

This page contains all the electrical diagrams for the component. rear window shade switch, in which he is found in the car Audi A8 D4 (2010-2014). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram rear window shade switch (1 of 2)

Wiring diagram rear window shade switch for Audi A8 D4 (2010-2014)

Get access

BLU WIRE BLU/VIO WIRE BRN WIRE CENTER INSTRUMENT PANEL VENT ILLUMINATION LAMP CIGARETTE LIGHTER ILLUMINATION LAMP COMPT) COMPUTER DATA LINES SYSTEM CUP HOLDER ILLUMINATION LAMP RIGHT, LEFT REAR UPPER BODY ILLUMINATION LAMP EMERGENCY FLASHER SWITCH, EMERGENCY FLASHER INDICATOR LAMP FRONT CENTER CONSOLE AMBIENT LIGHTING FUSE CARRIER 2 FUSE 1 FUSE CARRIER FUSE 9 FUSE PANEL C (LEFT END FUSE PANEL F (RIGHT FRONT LUGGAGE GRY WIRE GRY/BLU WIRE GRY/WHT WIRE HOT AT ALL TIMES INSTRUMENT CLUSTER CONTROL MODULE LEFT INSTRUMENT PANEL VENT ILLUMINATION LAMP LEFT REAR AIR VENT ILLUMINATION LAMP LEFT REAR, RIGHT REAR DOOR STORAGE COMPARTMENT ILLUMINATION LAMP OF DASH) ORG/BLU WIRE ORG/BRN WIRE REAR CENTER CONSOLE AMBIENT LIGHTING REAR WINDOW SHADE SWITCH RED WIRE RED/BLU WIRE RED/VIO WIRE RED/WHT WIRE RIGHT INSTRUMENT PANEL VENT ILLUMINATION LAMP RIGHT REAR AIR REAR CENTER AIR VENT ILLUMINATION LAMP VALET PARKING LOCK SWITCH VENT ILLUMINATION LAMP VIO WIRE WHT WIRE YEL/WHT WIRE

Go to component: -> Instrument illumination circuit (2 of 5) -> REAR WINDOW SHADE SWITCH

Wiring diagram rear window shade switch (2 of 2)

Wiring diagram rear window shade switch for Audi A8 D4 (2010-2014)

Get access

BLU/BLK WIRE BLU/BRN WIRE BLU/VIO WIRE BRN WIRE COMPUTER DATA LINES SYSTEM FUSE 11 FUSE CARRIER FUSE CARRIER 3 FUSE 3 FUSE FUSE FUSE PANEL C (LEFT END OF DASH) FUSE PANEL F (RIGHT FRONT LUGGAGE COMPT) GRN WIRE GRN/BLK WIRE GRY/RED WIRE HOT AT ALL TIMES LEFT REAR DOOR REAR WINDOW SHADE SWITCH LEFT REAR WINDOW SHADE CONTROL MODULE LEFT REAR WINDOW SHADE MOTOR ORG/BRN WIRE ORG/GRN WIRE REAR SUN SHADE MOTOR REAR WINDOW SHADE SWITCH RED/BLU WIRE RED/GRY WIRE RED/WHT WIRE RIGHT REAR DOOR REAR WINDOW SHADE SWITCH RIGHT REAR WINDOW SHADE CONTROL MODULE RIGHT REAR WINDOW SHADE MOTOR WHT WIRE WHT/RED WIRE

Go to component: -> Rear window sun shade circuit -> REAR WINDOW SHADE SWITCH
