Audi A8 D4 (2010-2014) rear cigarette lighter Wiring diagrams
This page contains all the electrical diagrams for the component. rear cigarette lighter, in which he is found in the car Audi A8 D4 (2010-2014). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram rear cigarette lighter (1 of 2)
BLU WIRE
BLU/BRN WIRE
BLU/WHT WIRE
BRN WIRE
FUSE 3
FUSE CARRIER 2 FUSE 8
FUSE CARRIER 3 FUSE 3
FUSE CARRIER 3 FUSE 5
FUSE PANEL B (RIGHT END OF DASH)
FUSE PANEL C (LEFT END OF DASH)
FUSE PANEL F (RIGHT FRONT LUUGAGE COMPT)
GRY WIRE
GRY/BLU WIRE
HOT AT ALL TIMES
LEFT SEAT HEATING BUTTON (AUTOMATIC CLIMATE CONTROL)
REAR CIGARETTE LIGHTER
RED WIRE
RED/WHT WIRE
RIGHT REAR EXTERIOR DOOR HANDLE ILLUMINATION LAMP
RIGHT REAR SEAT ADJUSTMENT CONTROL HEAD
RIGHT SEAT HEATING BUTTON (AUTOMATIC CLIMATE CONTROL)
SOCKET 2
SOCKET 3
STORAGE COMPARTMENT ILLUMINATION LAMP (W/ TELEPHONE RECEIVER)
WHT WIRE
Go to component -> Instrument illumination circuit (4 of 5) -> REAR CIGARETTE LIGHTER
Wiring diagram rear cigarette lighter (2 of 2)
12 V SOCKET 3
12 V SOCKET SOCKET 2
12-PIN CONNECTOR
BLK WIRE
BLU WIRE
BRN WIRE
CIGARETTE LIGHTER
COMFORT SYSTEM CENTRAL CONTROL MODULE
COMFORT SYSTEM CENTRAL CONTROL MODULE 2
CONVERTER W/ SOCKET,
COOLER
DATA BUS ON BOARD DIAGNOSTIC INTERFACE
ELECTROMECHANICAL PARKING BRAKE CONTROL MODULE
FROM FUSE PANEL F (DIAGRAM 5 OF 8)
FROM FUSE PANEL F (DIAGRAM 7 OF 8)
FROM SAFETY FUSE ASSEMBLY (DIAGRAM 1 OF 8)
FUEL PUMP RELAY
FUSE 10
FUSE 11
FUSE 12
FUSE 13
FUSE 14
FUSE 15
FUSE 16
FUSE 2 FUSE 3
FUSE 4
FUSE 5
FUSE 6
FUSE 7
FUSE 8
FUSE 9
FUSE CARRIER 3
FUSE CARRIER 4
FUSE PANEL F
GRN WIRE
GRY WIRE
LEVEL (UNDER SYSTEM REAR CONTROL CENTER MODULE CONSOLE)
NCA WIRE
REAR CIGARETTE LIGHTER
REAR TELEPHONE CHARGING STATION
RED WIRE
SELECTOR LEVER SENSOR SYSTEM CONTROL MODULE
SOCKETS RELAY (IN RELAY & FUSE CARRIER, RIGHT SIDE OF LUGGAGE COMPT)
TELEPHONE BASEPLATE
VIO WIRE
YEL WIRE
Go to component -> Power distribution circuit (6 of 8) -> REAR CIGARETTE LIGHTER
