Audi A8 D4 (2010-2014) power adjustable steering column control Wiring diagram
This page shows the only wiring diagram for the component.power adjustable steering column control, which is found in the car Audi A8 D4 (2010-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram power adjustable steering column control (1 of 1)
ACTIVE STEERING CONTROL MODULE
BLK WIRE
BLU WIRE
BRAKE BOOSTER RELAY
DATA MODULE LINK CONNECTOR
DRIVER MULTICONTOUR SEAT CONTROL MODULE
DRIVER'S DOOR CONTROL MODULE
FROM SAFETY FUSE ASSEMBLY (DIAGRAM 1 OF 8)
FUSE 1 FUSE 2
FUSE 1 FUSE 3
FUSE 10 FUSE 11
FUSE 10 FUSE 11 FUSE 12 FUSE 13
FUSE 12 40
FUSE 14
FUSE 15
FUSE 2
FUSE 3 FUSE 4
FUSE 4
FUSE 5
FUSE 6
FUSE 6 FUSE 7
FUSE 7
FUSE 8
FUSE 9
FUSE CARRIER 3
FUSE FUSE 16 CARRIER 2
FUSE PANEL C
GRN WIRE
GRY WIRE
LEFT REAR DOOR CONTROL MODULE
LEFT REAR DOOR HORN CONTROL RELAY MODULE
LIGHT ANTI-THEFT SWITCH IMMOBILIZER READER COIL
NCA WIRE
POWER ADJUSTABLE STEERING COLUMN CONTROL
POWER SUNROOF CONTROL MODULE
RAIN/LIGHT ELECTRONIC RECOGNITION STEERING COLUMN SENSOR LOCK CONTROL MODULE
RED WIRE
ROOF SHADE CONTROL MODULE
ROOF SHADE CONTROL MODULE 2
STEERING COLUMN ELECTRONICS CONTROL MODULE ROOF ELECTRONICS CONTROL MODULE
SUPPRESSOR
VEHICLE ELECTRICAL SYSTEM CONTROL MODULE
VIO WIRE
WHT WIRE
WIPER MOTOR CONTROL MODULE
YEL WIRE
Go to component: -> Power distribution circuit (2 of 8) -> POWER ADJUSTABLE STEERING COLUMN CONTROL
