Audi A8 D4 (2010-2014) parking lock solenoid Wiring diagram
This page shows the only wiring diagram for the component.parking lock solenoid, which is found in the car Audi A8 D4 (2010-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram parking lock solenoid (1 of 1)
ACCESS/START AUTHORIZATION BUTTON
ACCUMULATOR SOLENOID
AUTOMATIC TRANSMISSION PRESSURE REGULATING VALVE 1
AUTOMATIC TRANSMISSION PRESSURE REGULATING VALVE 2
AUTOMATIC TRANSMISSION PRESSURE REGULATING VALVE 3
AUTOMATIC TRANSMISSION PRESSURE REGULATING VALVE 4
AUTOMATIC TRANSMISSION PRESSURE REGULATING VALVE 5
AUTOMATIC TRANSMISSION PRESSURE REGULATING VALVE 6
AUTOMATIC TRANSMISSION PRESSURE REGULATING VALVE 7
BLK/GRN WIRE
BLK/WHT WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
FUSE CARRIER 2 FUSE 2
FUSE CARRIER 3 FUSE 12
FUSE CARRIER FUSE 10
FUSE CARRIER FUSE 12
FUSE PANEL B (RIGHT END OF DASH)
FUSE PANEL F (RIGHT FRONT LUGGAGE COMPT)
GRN WIRE
GRY/BLU WIRE
GRY/GRN WIRE
GRY/YEL WIRE
HOT AT ALL TIMES
HOT W/ POWER SUPPLY RELAY 2 (TERMINAL 15) ENERGIZED
NCA WIRE
ORG/BLK WIRE
ORG/BRN WIRE
ORG/WHT WIRE
PARKING LOCK SENSOR
PARKING LOCK SOLENOID
RED/GRN WIRE
RED/GRY WIRE
SELECTOR LEVER POSITION SENSOR
SELECTOR LEVER SENSOR SYSTEM CONTROL MODULE
SOLENOID VALVE 1
TRANSMISSION CONTROL MODULE (TCM) (IN BOTTOM OF TRANSMISSION)
TRANSMISSION FLUID TEMPERATURE SENSOR
TRANSMISSION INPUT SPEED SENSOR
TRANSMISSION OUTPUT SPEED SENSOR
VEHICLE ELECTRICAL SYSTEM CONTROL MODULE (BEHIND LEFT SIDE OF DASH)
VIO/GRN WIRE
Go to component: -> A/t circuit (1 of 3) -> PARKING LOCK SOLENOID
