Audi A8 D4 (2010-2014) left rear door opener illumination lamp Wiring diagram

BLU WIRE BLU/BRN WIRE BLU/VIO WIRE BLU/WHT WIRE BRN WIRE COURTESY LAMPS CIRCUIT FOG LAMP BUTTON FOG LAMP INDICATOR GRY WIRE GRY/BLU WIRE HANDLE ILLUMINATION LAMP HEADLAMP SWITCH ILLUMINATION INSTRUMENT PANEL, SWITCH ILLUMINATION DIMMER SWITCH LEFT REAR ASHTRAY ILLUMINATION LAMP LEFT REAR DOOR OPENER ILLUMINATION LAMP LEFT REAR EXTERIOR DOOR LEFT REAR INTERIOR LOCKING SWITCH LEFT REAR POWER WINDOW BUTTON LEFT REAR SEAT ADJUSTMENT CONTROL HEAD LEFT REAR SWITCH ILLUMINATION LAMP LIGHT SWITCH NIGHT VISION SYSTEM BUTTON PARKING LAMP INDICATOR REAR FOG LAMP BUTTON REAR FOG LAMP INDICATOR RED WIRE RED/BLU WIRE RED/WHT WIRE RIGHT REAR ASHTRAY ILLUMINATION LAMP RIGHT REAR DOOR OPENER ILLUMINATION LAMP RIGHT REAR INTERIOR LOCKING SWITCH RIGHT REAR POWER WINDOW BUTTON RIGHT REAR SWITCH ILLUMINATION LAMP STORAGE COMPARTMENT ILLUMINATION LAMP (W/O TELEPHONE RECEIVER) VEHICLE ELECTRICAL SYSTEM CONTROL MODULE (BEHIND LEFT SIDE OF DASH) VIO WIRE VIO/BLU WIRE VIO/BRN WIRE WHT WIRE YEL WIRE YEL/BRN WIRE
