Audi A8 D4 (2010-2014) front passenger active head restraint igniter Wiring diagram

This page shows the only wiring diagram for the component.front passenger active head restraint igniter, which is found in the car Audi A8 D4 (2010-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram front passenger active head restraint igniter (1 of 1)

Wiring diagram front passenger active head restraint igniter for Audi A8 D4 (2010-2014)

Get access

AIR BAG CONTROL MODULE (BELOW CENTER OF DASH, ON BLK WIRE BLK/BRN WIRE BLK/YEL WIRE BLU WIRE BRN WIRE BRN/BLK WIRE DRIVER ACTIVE HEAD RESTRAINT IGNITER DRIVER HEAD CURTAIN AIR BAG IGNITER (LEFT MIDDLE SIDE ROOF TRIM) DRIVER KNEE AIR BAG IGNITER DRIVER SEAT BELT SWITCH DRIVER THORAX AIR BAG IGNITER FRONT PASSENGER ACTIVE HEAD RESTRAINT IGNITER FRONT PASSENGER HEAD CURTAIN AIR BAG IGNITER (RIGHT MIDDLE SIDE ROOF TRIM) FRONT PASSENGER KNEE AIR BAG IGNITER GRN WIRE GRN/GRY WIRE GRN/RED WIRE GRN/YEL WIRE GRY WIRE IGNITER IGNITER LEFT REAR SEAT BELT TENSIONER IGNITER (TOP LEFT REAR PASSENGER SEAT) NCA WIRE RED WIRE RIGHT REAR SEAT BELT TENSIONER IGNITER (TOP RIGHT REAR PASSENGER SEAT) TRANSMISSION TUNNEL) VALVE IGNITER VIO WIRE WHT WIRE YEL WIRE YEL/BLU WIRE

Go to component: -> Supplemental restraints circuit (3 of 3) -> FRONT PASSENGER ACTIVE HEAD RESTRAINT IGNITER
