Audi A8 D4 (2010-2014) fiber optic cable for front center console ambient lighting Wiring diagram
This page shows the only wiring diagram for the component.fiber optic cable for front center console ambient lighting, which is found in the car Audi A8 D4 (2010-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram fiber optic cable for front center console ambient lighting (1 of 1)
ABS CONTROL MODULE
ACCESS/START AUTHORIZATION BUTTON
ANTENNA AMPLIFIER
BLK WIRE
BRN WIRE
BRN/GRN WIRE
CIGARETTE LIGHTER, CIGARETTE LIGHTER ILLUMINATION BULB
CLIMATRONIC CONTROL MODULE, DVD CHARGER
COOLER
DIGITAL SOUND SYSTEM CONTROL MODULE, DIGITAL SOUND SYSTEM CONTROL MODULE 2
FIBER OPTIC CABLE FOR FRONT CENTER CONSOLE AMBIENT LIGHTING
FUEL PUMP CONTROL MODULE, TRANSFER FUEL PUMP (6.3L)
IGNITION COILS 1, 2, 3, 4, 5, 6 (6.3L), IGNITION COILS 1, 2, 3, 4 (4.2L)
LANE CHANGE ASSISTANCE CONTROL MODULE, LANE CHANGE ASSISTANCE CONTROL MODULE 2
NCA WIRE
PERIPHERAL CAMERA CONTROL MODULE
TRANSFER FUEL PUMP (4.2L)
W/ ADJUSTABLE SEATS
W/O ADJUSTABLE SEATS W/ REAR HEATED SEAT VENTILATION
Go to component: -> Ground distribution circuit (1 of 3) -> FIBER OPTIC CABLE FOR FRONT CENTER CONSOLE AMBIENT LIGHTING
