Audi A8 D4 (2010-2014) driver window regulator motor Wiring diagram
This page shows the only wiring diagram for the component.driver window regulator motor, which is found in the car Audi A8 D4 (2010-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram driver window regulator motor (1 of 1)
BLK WIRE
BLK/GRN WIRE
BLU/BRN WIRE
BLU/GRN WIRE
BLU/RED WIRE
BLU/WHT WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
DOOR WINDOW REGULATOR MOTOR)
DRIVER DOOR CONTROL MODULE (INTEGRATED IN DRIVER'S DOOR WINDOW REGULATOR MOTOR)
DRIVER DOOR POWER WINDOW CONTROL HEAD
DRIVER WINDOW REGULATOR MOTOR
DRIVER'S LEFT REAR WINDOW REGULATOR SWITCH
DRIVER'S RIGHT FRONT POWER WINDOW SWITCH
DRIVER'S RIGHT REAR WINDOW REGULATOR SWITCH
FUSE 11
FUSE 5
FUSE CARRIER 3
FUSE PANEL C (LEFT END OF DASH)
GRN/BLK WIRE
HOT AT ALL TIMES
INTERIOR LIGHTS SYSTEM, DOOR LOCKS SYSTEMS
LEFT CHILD SAFETY BUTTON
LEFT FRONT WINDOW REGULATOR SWITCH
LEFT REAR DOOR CONTROL MODULE (INTEGRATED IN LEFT REAR
LEFT REAR POWER WINDOW
LEFT REAR POWER WINDOW BUTTON (IN LEFT REAR DOOR)
ORG/BRN WIRE
ORG/GRN WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/VIO WIRE
RED/WHT WIRE
RIGHT CHILD SAFETY BUTTON
RIGHT REAR POWER WINDOW
W/ PANORAMA SUNROOF
W/ SUNSHADE
W/O PANORAMA SUNROOF
W/O SUNSHADE
WHT/YEL WIRE
YEL/BLK WIRE
YEL/GRY WIRE
Go to component: -> Power windows circuit (1 of 2) -> DRIVER WINDOW REGULATOR MOTOR
