Audi A8 D4 (2010-2014) driver vanity mirror lamp contact switch Wiring diagram
This page shows the only wiring diagram for the component.driver vanity mirror lamp contact switch, which is found in the car Audi A8 D4 (2010-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram driver vanity mirror lamp contact switch (1 of 1)
ALL TIMES
BLK WIRE
BRN WIRE
BRN/YEL WIRE
COMPUTER DATA LINES SYSTEM
DRIVER VANITY MIRROR LAMP
DRIVER VANITY MIRROR LAMP CONTACT SWITCH
FRONT PASSENGER VANITY MIRROR LAMP
FRONT PASSENGER VANITY MIRROR LAMP CONTACT SWITCH
FUSE
FUSE CARRIER 2 FUSE
FUSE FUSE CARRIER
FUSE PANEL B (RIGHT END OF DASH)
FUSE PANEL C (LEFT END
GLOVE COMPART- MENT LAMP
GLOVE COMPART- MENT LAMP SWITCH
GRN WIRE
HOT AT ALL TIMES
INSTRUMENT ILLUMINATION CIRCUIT
LAMP
LEFT FRONT FOOTWELL ILLUMINATION
LEFT ILLUMINATED VANITY MIRROR
LEFT REAR DOOR CONTROL MODULE (INTEGRATED IN LEFT REAR DOOR WINDOW REGULATOR)
LEFT REAR DOOR WARNING LAMP
LEFT REAR ENTRY LAMP
LUGGAGE COMPARTMENT LAMP
MOTOR
OF DASH)
ORG/BRN WIRE
ORG/GRN WIRE
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/VIO WIRE
RED/WHT WIRE
RED/YEL WIRE
RIGHT FRONT FOOTWELL ILLUMINATION
RIGHT ILLUMINATED VANITY MIRROR
RIGHT REAR DOOR WARNING LAMP (W/ AUXILIARY LAMPS)
RIGHT REAR ENTRY LAMP
VEHICLE ELECTRICAL SYSTEM CONTROL MODULE (BEHIND LEFT SIDE OF DASH)
VIO WIRE
W/ AUXILIARY LAMPS
WHT WIRE
WHT/RED WIRE
YEL WIRE
Go to component: -> Courtesy lamp circuit (1 of 3) -> DRIVER VANITY MIRROR LAMP CONTACT SWITCH
