Audi A8 D4 (2010-2014) driver active head restraint igniter Wiring diagram
This page shows the only wiring diagram for the component.driver active head restraint igniter, which is found in the car Audi A8 D4 (2010-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram driver active head restraint igniter (1 of 1)
AIR BAG CONTROL MODULE (BELOW CENTER OF DASH, ON
BLK WIRE
BLK/BRN WIRE
BLK/YEL WIRE
BLU WIRE
BRN WIRE
BRN/BLK WIRE
DRIVER ACTIVE HEAD RESTRAINT IGNITER
DRIVER HEAD CURTAIN AIR BAG IGNITER (LEFT MIDDLE SIDE ROOF TRIM)
DRIVER KNEE AIR BAG IGNITER
DRIVER SEAT BELT SWITCH
DRIVER THORAX AIR BAG IGNITER
FRONT PASSENGER ACTIVE HEAD RESTRAINT IGNITER
FRONT PASSENGER HEAD CURTAIN AIR BAG IGNITER (RIGHT MIDDLE SIDE ROOF TRIM)
FRONT PASSENGER KNEE AIR BAG IGNITER
GRN WIRE
GRN/GRY WIRE
GRN/RED WIRE
GRN/YEL WIRE
GRY WIRE
IGNITER IGNITER
LEFT REAR SEAT BELT TENSIONER IGNITER (TOP LEFT REAR PASSENGER SEAT)
NCA WIRE
RED WIRE
RIGHT REAR SEAT BELT TENSIONER IGNITER (TOP RIGHT REAR PASSENGER SEAT)
TRANSMISSION TUNNEL)
VALVE IGNITER
VIO WIRE
WHT WIRE
YEL WIRE
YEL/BLU WIRE
Go to component: -> Supplemental restraints circuit (3 of 3) -> DRIVER ACTIVE HEAD RESTRAINT IGNITER
