Audi A8 D4 (2010-2014) central locking safe indicator lamp Wiring diagram
This page shows the only wiring diagram for the component.central locking safe indicator lamp, which is found in the car Audi A8 D4 (2010-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram central locking safe indicator lamp (1 of 1)
ALARM SYSTEM DEACT- IVATION SWITCH
BLK WIRE
BLU WIRE
BLU/BRN WIRE
BLU/WHT WIRE
BRN WIRE
BRN/GRN WIRE
CENTRAL LOCKING SAFE INDICATOR LAMP
COMPUTER DATA LINES SYSTEM
COURTESY LAMPS CIRCUIT
DRIVER MEMORY SEAT CONTROL HEAD
DRIVER'S DOOR CONTROL MODULE
DRIVER'S DOOR OPENER ILLUMINATION LAMP
DRIVER'S INTERIOR LOCKING SWITCH
FRONT PASSENGER DOOR OPENER ILLUMINATION LAMP
FRONT PASSENGER DOOR WINDOW REGULATOR
FRONT PASSENGER MEMORY SEAT CONTROL HEAD
FRONT PASSENGER'S DOOR CONTROL MODULE
FRONT SIDE PASSENGER INTERIOR LOCKING
GRN WIRE
GRY WIRE
LANE CHANGE ASSISTANCE BUTTON
LEFT FRONT EXTERIOR DOOR HANDLE ILLUMINATION LAMP
LEFT FRONT WINDOW REGULATOR SWITCH
MIRROR ADJUSTING SWITCH
ORG/BRN WIRE
ORG/GRN WIRE
REAR LID REMOTE RELEASE BUTTON
RED/WHT WIRE
RIGHT FRONT EXTERIOR DOOR HANDLE ILLUMINATION LAMP
SWITCH
VIO WIRE
VIO/BLU WIRE
WHT WIRE
Go to component: -> Instrument illumination circuit (5 of 5) -> CENTRAL LOCKING SAFE INDICATOR LAMP
