Audi A8 D4 (2010-2014) brn Wiring diagrams
This page contains all the electrical diagrams for the component. brn, in which he is found in the car Audi A8 D4 (2010-2014). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram brn (121 of 130)
ACCESS/START AUTHORIZATION BUTTON
ACCUMULATOR SOLENOID
AUTOMATIC TRANSMISSION PRESSURE REGULATING VALVE 1
AUTOMATIC TRANSMISSION PRESSURE REGULATING VALVE 2
AUTOMATIC TRANSMISSION PRESSURE REGULATING VALVE 3
AUTOMATIC TRANSMISSION PRESSURE REGULATING VALVE 4
AUTOMATIC TRANSMISSION PRESSURE REGULATING VALVE 5
AUTOMATIC TRANSMISSION PRESSURE REGULATING VALVE 6
AUTOMATIC TRANSMISSION PRESSURE REGULATING VALVE 7
BLK/GRN WIRE
BLK/WHT WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
FUSE CARRIER 2 FUSE 2
FUSE CARRIER 3 FUSE 12
FUSE CARRIER FUSE 10
FUSE CARRIER FUSE 12
FUSE PANEL B (RIGHT END OF DASH)
FUSE PANEL F (RIGHT FRONT LUGGAGE COMPT)
GRN WIRE
GRY/BLU WIRE
GRY/GRN WIRE
GRY/YEL WIRE
HOT AT ALL TIMES
HOT W/ POWER SUPPLY RELAY 2 (TERMINAL 15) ENERGIZED
NCA WIRE
ORG/BLK WIRE
ORG/BRN WIRE
ORG/WHT WIRE
PARKING LOCK SENSOR
PARKING LOCK SOLENOID
RED/GRN WIRE
RED/GRY WIRE
SELECTOR LEVER POSITION SENSOR
SELECTOR LEVER SENSOR SYSTEM CONTROL MODULE
SOLENOID VALVE 1
TRANSMISSION CONTROL MODULE (TCM) (IN BOTTOM OF TRANSMISSION)
TRANSMISSION FLUID TEMPERATURE SENSOR
TRANSMISSION INPUT SPEED SENSOR
TRANSMISSION OUTPUT SPEED SENSOR
VEHICLE ELECTRICAL SYSTEM CONTROL MODULE (BEHIND LEFT SIDE OF DASH)
VIO/GRN WIRE
Go to component: -> A/t circuit (1 of 3) -> BRN WIRE
Wiring diagram brn (122 of 130)
AIR BAG SPIRAL SPRING/RETURN SPRING W/ SLIP RING
BLK/BRN WIRE
BLK/GRN WIRE
BRN WIRE
COMFORT SYSTEM CENTRAL CONTROL
COMPUTER DATA LINES SYSTEM
FUSE 11
FUSE CARRIER 1 FUSE 5
FUSE PANEL A (RIGHT SIDE OF ENGINE COMPT)
FUSE PANEL F (RIGHT FRONT LUGGAGE COMPT)
GRY/BLU WIRE
HOT W/ ENGINE COMPONENT POWER SUPPLY RELAY ENERGIZED
HOT W/ POWER SUPPLY RELAY 2 (TERMINAL 15) ENERGIZED
LEFT MULTI-FUNCTION BUTTONS
MODE
MODULE (RIGHT SIDE OF LUGGAGE COMPT)
MULTI-FUNCTION STEERING WHEEL CONTROL MODULE
NCA WIRE
ORG/BLK WIRE
ORG/BLU WIRE
ORG/BRN WIRE
ORG/GRN WIRE
RED/WHT WIRE
RIGHT MULTI-FUNCTION BUTTONS
STEERING COLUMN ELECTRONICS CONTROL MODULE (TOP OF STEERING COLUMN)
STEERING WHEEL CONTROL MODULE
TIPTRONIC DOWNSHIFT BUTTON
TIPTRONIC UPSHIFT BUTTON
TRANSMISSION FLUID COOLING VALVE (IN LOWER LEFT ENGINE COMPT)
VIO/GRN WIRE
Go to component: -> A/t circuit (3 of 3) -> BRN WIRE
Wiring diagram brn (123 of 130)
ALL WHEEL DRIVE CLUTCH VALVE (ON TRANSMISSION)
ALL WHEEL DRIVE CLUTCH VALVE 2 (ON TRANSMISSION)
ALL WHEEL DRIVE PUMP
ALL- WHEEL DRIVE CONTROL MODULE
BLK WIRE
BLU WIRE
BRN WIRE
BRN/BLK WIRE
COMPUTER DATA LINES SYSTEM
CONTROL UNIT)
FUSE
FUSE PANEL D
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
LEVEL CONTROL SYSTEM CONTROL MODULE (RIGHT SIDE OF LUGGAGE COMPT)
OIL PRESSURE/ TEMPERATURE SENSOR (ON HYDRAULIC
OIL PRESSURE/ TEMPERATURE SENSOR 2 (ON HYDRAULIC
ORG/BLK WIRE
ORG/BRN WIRE
PNK WIRE
RED WIRE
RED/BLK WIRE
RED/GRN WIRE
RED/YEL WIRE
WHT WIRE
WHT/RED WIRE
YEL WIRE
YEL/BLK WIRE
YEL/RED WIRE
Go to component: -> Awd circuit -> BRN WIRE
Wiring diagram brn (124 of 130)
BLK WIRE
BLK/BLU WIRE
BLU WIRE
BLU/RED WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
FUSE 1
FUSE PANEL FUSE CARRIER 1 (RIGHT FRONT LUGGAGE COMPT)
GRY WIRE
HOT W/ POWER SUPPLY RELAY 2 (TERMINAL 15) ENERGIZED
INSTRUMENT CLUSTER CONTROL MODULE
LEFT FRONT BRAKE PAD WEAR SENSOR
LEFT REAR BRAKE PAD WEAR SENSOR
ORG/BLU WIRE
ORG/BRN WIRE
ORG/GRN WIRE
RED WIRE
RIGHT FRONT BRAKE PAD WEAR SENSOR
RIGHT REAR BRAKE PAD WEAR SENSOR
VEHICLE ELECTRICAL SYSTEM CONTROL MODULE (BEHIND LEFT SIDE OF DASH)
WHT WIRE
Go to component: -> Brake wear sensor circuit -> BRN WIRE
Wiring diagram brn (125 of 130)
AIR BAG CONTROL MODULE (BELOW CENTER OF DASH, ON TRANSMISSION TUNNEL)
AIR BAG SPIRAL SPRING/
BATTERY INTERRUPT IGNITER
BLK WIRE
BLK/BRN WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU WIRE
BLU/WHT WIRE
BRN WIRE
BRN/GRY WIRE
BRN/RED WIRE
COMPUTER DATA LINES SYSTEM
DRIVER AIRBAG RELEASE VALVE IGNITER
DRIVER FRONT AIR BAG CRASH SENSOR (LEFT FRONT OF ENGINE COMPT)
DRIVER SIDE AIR BAG CRASH SENSOR (AT LEFT "B" PILLAR)
DRIVER SIDE REAR SIDE AIR BAG CRASH SENSOR (AT BOTTOM OF LEFT "C" PILLAR)
DRIVER SIDE REAR THORAX AIR BAG IGNITER
FRONT PASSENGER FRONT AIR BAG CRASH SENSOR (RIGHT FRONT OF ENGINE COMPT)
FRONT PASSENGER REAR THORAX AIR BAG IGNITER
FRONT PASSENGER SIDE AIR BAG CRASH SENSOR (AT RIGHT "B" PILLAR)
FRONT PASSENGER'S AIR BAG DISABLED INDICATOR LAMP
FUSE CARRIER FUSE 7
FUSE PANEL D
FUSE PANEL F (RIGHT FRONT LUGGAGE COMPT)
GRN WIRE
GRN/BLU WIRE
GRY WIRE
GRY/RED WIRE
HOT AT ALL TIMES
HOT W/ POWER SUPPLY RELAY (TERMINAL 15) ENERGIZED
NCA WIRE
ORG/BLK WIRE
ORG/BRN WIRE
POWER DISTRIBUTION SYSTEM
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RETURN SPRING (W/ SLIP RING)
SOLID STATE
VIO WIRE
VIO/BLK WIRE
WHT WIRE
YEL WIRE
Go to component: -> Supplemental restraints circuit (1 of 3) -> BRN WIRE
Wiring diagram brn (126 of 130)
AIR BAG INDICATOR LAMP
BLK WIRE
BLK/BRN WIRE
BLK/RED WIRE
BLK/YEL WIRE
BLU WIRE
BRN WIRE
BRN/BLK WIRE
COMPUTER DATA LINES SYSTEM
FORCE LIMITER
FRONT PASSENGER SEAT OCCUPANT SENSOR
FRONT PASSENGER SEAT POSITION SENSOR
FRONT PASSENGER THORAX AIR BAG IGNITER
FUSE 1 FUSE 2
FUSE CARRIER 2
FUSE PANEL F (RIGHT FRONT LUGGAGE COMPT)
GRN WIRE
GRN/BLU WIRE
GRN/YEL WIRE
GRY WIRE
GRY/BRN WIRE
GRY/RED WIRE
HOT W/ POWER SUPPLY RELAY 2 (TERMINAL 15) ENERGIZED
IGNITER
INSTRUMENT CLUSTER
INSTRUMENT CLUSTER CONTROL MODULE
LEFT FRONT SEAT BELT TENSIONER CONTROL MODULE
NCA WIRE
ORG/ WIRE
PASSENGER OCCUPANT DETECTION SYSTEM CONTROL MODULE
PASSENGER OCCUPANT DETECTION SYSTEM PRESSURE SENSOR
RED WIRE
RED/BLK WIRE
RIGHT FRONT SEAT BELT TENSIONER CONTROL MODULE
SOLID STATE
VIO WIRE
WHT WIRE
YEL WIRE
Go to component: -> Supplemental restraints circuit (2 of 3) -> BRN WIRE
Wiring diagram brn (127 of 130)
AIR BAG CONTROL MODULE (BELOW CENTER OF DASH, ON
BLK WIRE
BLK/BRN WIRE
BLK/YEL WIRE
BLU WIRE
BRN WIRE
BRN/BLK WIRE
DRIVER ACTIVE HEAD RESTRAINT IGNITER
DRIVER HEAD CURTAIN AIR BAG IGNITER (LEFT MIDDLE SIDE ROOF TRIM)
DRIVER KNEE AIR BAG IGNITER
DRIVER SEAT BELT SWITCH
DRIVER THORAX AIR BAG IGNITER
FRONT PASSENGER ACTIVE HEAD RESTRAINT IGNITER
FRONT PASSENGER HEAD CURTAIN AIR BAG IGNITER (RIGHT MIDDLE SIDE ROOF TRIM)
FRONT PASSENGER KNEE AIR BAG IGNITER
GRN WIRE
GRN/GRY WIRE
GRN/RED WIRE
GRN/YEL WIRE
GRY WIRE
IGNITER IGNITER
LEFT REAR SEAT BELT TENSIONER IGNITER (TOP LEFT REAR PASSENGER SEAT)
NCA WIRE
RED WIRE
RIGHT REAR SEAT BELT TENSIONER IGNITER (TOP RIGHT REAR PASSENGER SEAT)
TRANSMISSION TUNNEL)
VALVE IGNITER
VIO WIRE
WHT WIRE
YEL WIRE
YEL/BLU WIRE
Go to component: -> Supplemental restraints circuit (3 of 3) -> BRN WIRE
Wiring diagram brn (128 of 130)
BLK WIRE
BRN WIRE
BRN/GRN WIRE
COMPUTER DATA LINES SYSTEM
FUSE 4
FUSE CARRIER 6
FUSE PANEL F (RIGHT FRONT LUGGAGE COMPT)
GRN/VIO WIRE
HOT AT ALL TIMES
LEFT FRONT TIRE PRESSURE MONITORING SENSOR
LEFT FRONT TIRE PRESSURE MONITORING TRANSMITTER
LEFT REAR TIRE PRESSURE MONITORING SENSOR
LEFT REAR TIRE PRESSURE MONITORING TRANSMITTER
ORG/BLU WIRE
ORG/BRN WIRE
RED WIRE
RED/BLK WIRE
RIGHT FRONT TIRE PRESSURE MONITORING SENSOR
RIGHT FRONT TIRE PRESSURE MONITORING TRANSMITTER
RIGHT REAR TIRE PRESSURE MONITORING SENSOR
RIGHT REAR TIRE PRESSURE MONITORING TRANSMITTER
TIRE PRESSURE MONITORING CONTROL MODULE (BELOW FRONT RIGHT SEAT)
YEL/BRN WIRE
YEL/GRY WIRE
Go to component: -> Tire pressure monitoring circuit -> BRN WIRE
Wiring diagram brn (129 of 130)
BLK WIRE
BLK/RED WIRE
BLU/BLK WIRE
BLU/BRN WIRE
BLU/VIO WIRE
BLU/YEL WIRE
BRN WIRE
BRN/BLU WIRE
COMPUTER DATA LINES SYSTEM
DOOR CLOSING ASSIST CONTROL MODULE (BELOW TRIM APRON RAIL)
DRIVER DOOR CONTROL MODULE
FRONT LUGGAGE COMPT)
FUSE 12 FUSE 11
FUSE 9
FUSE CARRIER 3 FUSE 5
FUSE FUSE 1 N/A CARRIER
FUSE PANEL C (LEFT END OF DASH)
FUSE PANEL F (RIGHT
GRN/BLU WIRE
GRN/RED WIRE
GRN/WHT WIRE
GRY WIRE
HOT AT ALL TIMES
NCA WIRE
ORG/BRN WIRE
ORG/GRN WIRE
POWER DISTRIBUTION SYSTEM
POWER REAR LID OPENER SENSOR (IF EQUIPPED)
REAR LID CENTRAL LOCKING SYSTEM MOTOR
REAR LID CONTROL MODULE (LEFT LUGGAGE COMPT, BEHIND SIDE PANEL)
REAR LID LOCK BUTTON
REAR LID LOCK CYLINDER UNLOCK BUTTON
REAR LID LOCK/ ALARM/CENTRAL LOCKING SWITCH
REAR LID MOTOR/REAR LID CLOSED SENSOR 1&2
REAR LID OPENER CONTROL MODULE
REAR LID OPENER SENSOR 2 (IF EQUIPPED)
REAR LID REMOTE RELEASE BUTTON
RED/BLU WIRE
RED/GRN WIRE
RED/VIO WIRE
RED/WHT WIRE
VIO/BLU WIRE
WHT WIRE
WHT/BLK WIRE
WHT/RED WIRE
YEL/BLU WIRE
Go to component: -> Trunk & fuel door release circuit -> BRN WIRE
Wiring diagram brn (130 of 130)
8 9 COMPUTER DATA LINES SYSTEM
BLK WIRE
BLK/BRN WIRE
BLK/VIO WIRE
BLU WIRE
BRN WIRE
BRN/BLU WIRE
COMPUTER DATA LINES SYSTEM
FUSE
FUSE 2
FUSE 8 CARRIER 2
FUSE 8 FUSE 5 CARRIER 1
FUSE CARRIER 3
FUSE FUSE 12 CARRIER 2
FUSE FUSE 15 FUSE 10 FUSE 3 FUSE 9 CARRIER 2 CARRIER 3
FUSE PANEL C (LEFT END OF DASH)
FUSE PANEL F (RIGHT FRONT LUGGAGE COMPT)
GRN WIRE
GRN/RED WIRE
GRY WIRE
HEADLAMP WASHER PUMP WINDSHIELD WASHER FLUID LEVEL SENSOR
HOT AT ALL TIMES
HOT W/ POWER SUPPLY (TERMINAL 15) RELAY 2
LEFT WASHER NOZZLE HEATER
NCA WIRE
ORG/BLK WIRE
ORG/BLU WIRE
ORG/BRN WIRE
ORG/GRN WIRE
RAIN/LIGHT RECOGNITION SENSOR
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/GRY WIRE
RED/VIO WIRE
RED/WHT WIRE
RIGHT WASHER NOZZLE HEATER
VEHICLE ELECTRICAL SYSTEM CONTROL MODULE (BEHIND LEFT SIDE OF DASH)
VIO WIRE
VIO/BLK WIRE
W/ HEATED STEERING WHEEL
W/O HEATED STEERING WHEEL
WHT WIRE
WHT/VIO WIRE
WINDSHIELD WASHER PUMP
WINDSHIELD WIPER MOTOR
WIPER MOTOR CONTROL MODULE
Go to component: -> Wiper/washer circuit -> BRN WIRE
