Audi A8 D4 (2010-2014) anti-theft alarm system sensor Wiring diagram
This page shows the only wiring diagram for the component.anti-theft alarm system sensor, which is found in the car Audi A8 D4 (2010-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram anti-theft alarm system sensor (1 of 1)
4.2L
6.3L
ABS CONTROL MODULE
ALARM HORN
ANTI-THEFT ALARM SYSTEM SENSOR
BLK WIRE
BLU WIRE
BRN WIRE
ENGINE CONTROL MODULE
ENGINE CONTROL MODULE 2
FRESH AIR BLOWER CONTROL MODULE
FROM RIGHT REAR SAFETY FUSE DOOR ASSEMBLY CONTROL (DIAGRAM MODULE 1 OF 8)
FROM SAFETY FUSE ASSEMBLY (DIAGRAM 1 OF 8)
FRONT PASSENGER DOOR CONTROL MODULE
FRONT PASSENGER MULTICONTOUR SEAT CONTROL MODULE
FUSE
FUSE 1
FUSE 11
FUSE 12
FUSE 2
FUSE 3
FUSE 4 FUSE 5
FUSE 6 FUSE 7
FUSE 8
FUSE 9 FUSE 10
FUSE 9 FUSE 10 FUSE 11
FUSE CARRIER 2
FUSE FUSE 12 CARRIER 3
FUSE PANEL B
GRN WIRE
GRY WIRE
NCA WIRE
RED WIRE
RIGHT END OF DASH)
STROBE LAMP RELAY (W/ POLICE SPECIAL EQUIPMENT)
TO ENGINE COMPONENT POWER SUPPLY RELAY ENGINE (DIAGRAM CONTROL 1 OF 8) MODULE
TRANSMISSION CONTROL MODULE
TWO- WAY RADIO (W/ TAXI EQUIPMENT)
TWO-WAY RADIO CUTOFF RELAY (W/ POLICE SPECIAL EQUIPMENT)
VIO WIRE
W/ TAXI EQUIPMENT W/ POLICE SPECIAL EQUIPMENT
WHT WIRE
YEL WIRE
Go to component: -> Power distribution circuit (3 of 8) -> ANTI-THEFT ALARM SYSTEM SENSOR
