Audi A8 D4 (2010-2014) all wheel drive pump Wiring diagram

This page shows the only wiring diagram for the component.all wheel drive pump, which is found in the car Audi A8 D4 (2010-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram all wheel drive pump (1 of 1)

Wiring diagram all wheel drive pump for Audi A8 D4 (2010-2014)

Get access

ALL WHEEL DRIVE CLUTCH VALVE (ON TRANSMISSION) ALL WHEEL DRIVE CLUTCH VALVE 2 (ON TRANSMISSION) ALL WHEEL DRIVE PUMP ALL- WHEEL DRIVE CONTROL MODULE BLK WIRE BLU WIRE BRN WIRE BRN/BLK WIRE COMPUTER DATA LINES SYSTEM CONTROL UNIT) FUSE FUSE PANEL D GRN WIRE GRY WIRE HOT AT ALL TIMES LEVEL CONTROL SYSTEM CONTROL MODULE (RIGHT SIDE OF LUGGAGE COMPT) OIL PRESSURE/ TEMPERATURE SENSOR (ON HYDRAULIC OIL PRESSURE/ TEMPERATURE SENSOR 2 (ON HYDRAULIC ORG/BLK WIRE ORG/BRN WIRE PNK WIRE RED WIRE RED/BLK WIRE RED/GRN WIRE RED/YEL WIRE WHT WIRE WHT/RED WIRE YEL WIRE YEL/BLK WIRE YEL/RED WIRE

Go to component: -> Awd circuit -> ALL WHEEL DRIVE PUMP
