Interior lights circuit for Audi A8 D3 facelift (2005-2007)

BRN WIRE CIGARETTE LIGHTER LIGHT COMBINATION PROCESSOR CUP HOLDER ILLUMINATION FOG LIGHT INDICATOR LIGHT FRONT/CENTER CONSOLE CONTROL HEAD FUSE 29 FUSE 5 GRY WIRE GRY/BLU WIRE GRY/YEL WIRE HEAD- LIGHT SWITCH LIGHT HOT AT ALL TIMES INSTRUMENT CLUSTER LEFT CENTER ARMREST ILLUMINATION LEFT CENTER INSTRUMENT PANEL VENT ILLUMINATION LEFT INSTRUMENT PANEL FUSE PANEL (BEHIND LEFT SIDE OF DASH) LEFT INSTRUMENT PANEL VENT ILLUMINATION LEFT REAR CENTER CONSOLE STORAGE ILLUMINATION LIGHT SWITCH NCA WIRE PARK LIGHT INDICATOR LIGHT PARKING BRAKE CONTACT SWITCH REAR CENTER CONSOLE STORAGE ILLUMINATION REAR CIGARETTE LIGHTER LIGHT REAR SEAT CENTER OUTLET LIGHT (BELOW DRIVER'S SEAT) REAR SEAT LEFT OUTLET LIGHT REAR SEAT RIGHT OUTLET LIGHT RED/YEL WIRE RIGHT CENTER ARMREST ILLUMINATION RIGHT CENTER INSTRUMENT PANEL VENT ILLUMINATION RIGHT INSTRUMENT PANEL VENT ILLUMINATION RIGHT REAR CENTER CONSOLE STORAGE ILLUMINATION STORAGE COMPARTMENT ILLUMINATION TELEMATIC CONTROL HEAD

BLK/RED WIRE BLU WIRE BRN WIRE COMFORT SYSTEM CENTRAL CONTROL MODULE (IN LUGGAGE COMPARTMENT, BEHIND BATTERY) FUSE 31 FUSE 6 FUSE 7 FUSE 5 GLOVE COMPARTMENT LIGHT GLOVE COMPARTMENT LIGHT SWITCH GRY/YEL WIRE HOT AT ALL TIMES LEFT FOOTWELL LIGHT LEFT INSTRUMENT PANEL FUSE PANEL (BEHIND LEFT SIDE OF DASH) LEFT LUGGAGE COMPARTMENT LIGHT LEFT REAR FOOTWELL LIGHT REAR LID COURTESY LIGHT REAR LID LOCK BUTTON (IN LUGG COMPT) RED/BLK WIRE RED/BLU WIRE RED/GRY WIRE RED/VIO WIRE RIGHT FOOTWELL LIGHT RIGHT LUGGAGE COMPARTMENT FUSE PANEL (RIGHT SIDE OF LUGGAGE COMPT) RIGHT LUGGAGE COMPARTMENT LIGHT RIGHT REAR FOOTWELL LIGHT (UNDER FRONT PASSENGER'S SEAT) TIPTRONIC SWITCH VIO/BLU WIRE VIO/WHT WIRE WHT/RED WIRE

AUTO AUTOMATIC DAY/NIGHT INTERIOR MIRROR BLU WIRE BLU/BLK WIRE BLU/BRN WIRE BLU/GRN WIRE BLU/GRY WIRE BLU/RED WIRE BLU/WHT WIRE BLU/YEL WIRE BRN WIRE BRN/WHT WIRE BRN/YEL WIRE COMPUTER DATA LINES SYSTEM DRIVER'S READING LIGHT BUTTON FRONT INTERIOR LAMP BUTTON AUTO ON FRONT PASSENGER'S READING LIGHT BUTTON FUSE 13 GARAGE DOOR OPENER CONTROL HEAD GRN WIRE GRN/BLK WIRE GRN/BLU WIRE GRN/BRN WIRE GRN/GRY WIRE GRN/RED WIRE GRN/WHT WIRE GRN/YEL WIRE HOT IN RUN AND START HUMIDITY SENSOR INTERIOR ILLUMINATION SWITCH SUNROOF SWITCH LIGHT LEFT FRONT READING LIGHT LEFT ILLUMINATED INTERIOR MAKE-UP MIRROR LEFT INSTRUMENT PANEL FUSE PANEL (BEHIND LEFT SIDE OF DASH) LEFT INTERIOR LIGHT LEFT MAKE-UP MIRROR LIGHT LEFT MAKE-UP MIRROR LIGHT SWITCH LEFT REAR INTERIOR LIGHT LEFT REAR READING LIGHT LEFT REAR READING LIGHT SWITCH LEFT REAR WINDOW SHADE BUTTON LIGHT RECOGNITION SENSOR OFF ORG/BRN WIRE ORG/GRN WIRE PASSENGER'S MAP/READING LIGHT POWER TOPS SYSTEM RADAR INTERIOR MONITORING CONTROL MODULE 1 REAR INTERIOR LAMP BUTTON REAR ROOF MODULE CONTROL HEAD REAR WINDOW SHADE SWITCH (REAR) RED/YEL WIRE RIGHT ILLUMINATED INTERIOR MAKE-UP MIRROR RIGHT INTERIOR LIGHT RIGHT MAKE-UP MIRROR LIGHT RIGHT REAR INTERIOR LIGHT RIGHT REAR READING LIGHT RIGHT REAR READING LIGHT SWITCH 1 RIGHT REAR WINDOW SHADE BUTTON ROOF ELECTRONICS CONTROL MODULE SUNROOF BUTTON SUNROOF REGULATOR VIO/BLU WIRE VIO/GRN WIRE VIO/WHT WIRE

ALARM SYSTEM-OFF-SWITCH/ PASSENGER COMPARTMENT MONITORING SWITCH BLK WIRE BLK/YEL WIRE BLU/YEL WIRE BRN WIRE BRN/GRY WIRE BRN/YEL WIRE CENTRAL LOCKING SAFE WARNING LIGHT DRIVER ENTRY LAMP (IN OUTSIDE MIRROR) DRIVER SIDE DOOR OPENER LIGHTING DRIVER SIDE DOOR WARNING LIGHT DRIVER SIDE INTERIOR LOCK SWITCH DRIVER'S DOOR AMBIENT ILLUMINATION DRIVER'S DOOR AMBIENT LIGHTING VOLTAGE CONVERTER DRIVER'S DOOR STORAGE ILLUMINATION DRIVER'S DOOR WINDOW REGULATOR CONTROL HEAD DRIVER'S SEAT MEMORY PROGRAM CONTROL DRIVER'S SIDE DOOR CONTACT SWITCH FUEL TANK LID UNLOCK/ REAR LID REMOTE CONTROL LOCK SWITCH FUSE 39 GRN WIRE GRN/WHT WIRE GRY/BLU WIRE GRY/VIO WIRE GRY/WHT WIRE HOT AT ALL TIMES LEFT FRONT ENTRY LIGHT LEFT FRONT OUTSIDE DOOR HANDLE ILLUMINATION LEFT INSTRUMENT PANEL FUSE PANEL (BEHIND LEFT SIDE OF DASH) MIRROR ADJUSTMENT SWITCH NCA WIRE RED/BLU WIRE RED/WHT WIRE RED/YEL WIRE SEAT MEMORY LOCK-OUT BUTTON YEL/BLU WIRE YEL/WHT WIRE

BLK WIRE BLK/YEL WIRE BLU/YEL WIRE BRN WIRE BRN/YEL WIRE FRONT PASSENGER EMERGENCY OFF BUTTON FRONT PASSENGER'S CENTRAL LOCKING SAFE INDICATOR LIGHT FRONT PASSENGER'S DOOR STORAGE ILLUMINATION FRONT PASSENGER'S ENTRY LAMP (IN OUTSIDE MIRROR) FUSE 39 GRN WIRE GRN/WHT WIRE GRY/BLU WIRE GRY/VIO WIRE HOT AT ALL TIMES NCA WIRE PASSENGER DOOR WINDOW REGULATOR SWITCH PASSENGER SIDE DOOR OPENER LIGHTING PASSENGER SIDE DOOR WARNING LIGHT PASSENGER SIDE INTERIOR LOCK SWITCH PASSENGER'S DOOR AMBIENT ILLUMINATION PASSENGER'S DOOR AMBIENT LIGHTING VOLTAGE CONVERTER PASSENGER'S SEAT MEMORY PROGRAM CONTROL PASSENGER'S SIDE DOOR CONTACT SWITCH RED/BLU WIRE RED/WHT WIRE RIGHT FRONT ENTRY LIGHT RIGHT FRONT OUTSIDE DOOR HANDLE ILLUMINATION RIGHT INSTRUMENT PANEL FUSE PANEL (BEHIND RIGHT SIDE OF DASH)

BLU/YEL WIRE BRN WIRE BRN/GRY WIRE FUSE 41 GRN WIRE GRN/WHT WIRE GRY/BLU WIRE GRY/VIO WIRE HOT AT ALL TIMES LEFT INSTRUMENT PANEL FUSE PANEL (BEHIND LEFT SIDE OF DASH) LEFT REAR ASHTRAY LIGHT LEFT REAR DOOR AMBIENT ILLUMINATION LEFT REAR DOOR AMBIENT LIGHTING VOLTAGE CONVERTER LEFT REAR DOOR CONTACT SWITCH LEFT REAR DOOR OPENER LIGHTING LEFT REAR DOOR STORAGE ILLUMINATION LEFT REAR DOOR WARNING LIGHT LEFT REAR ENTRY LIGHT LEFT REAR INTERIOR LOCK SWITCH LEFT REAR OUTSIDE DOOR HANDLE ILLUMINATION LEFT REAR WINDOW SWITCH NCA WIRE RED/BLU WIRE RED/WHT WIRE RED/YEL WIRE

BLU/YEL WIRE BRN WIRE BRN/GRY WIRE FUSE 41 GRN WIRE GRN/WHT WIRE GRY/BLU WIRE GRY/VIO WIRE HOT AT ALL TIMES LEFT REAR DOOR AMBIENT ILLUMINATION LEFT REAR DOOR AMBIENT LIGHTING VOLTAGE CONVERTER NCA WIRE PASSENGER'S SEAT ADJUSTING SWITCH RED/BLU WIRE RED/WHT WIRE RED/YEL WIRE RIGHT INSTRUMENT PANEL FUSE PANEL (BEHIND RIGHT SIDE OF DASH) RIGHT REAR ASHTRAY LIGHT RIGHT REAR DOOR CONTACT SWITCH RIGHT REAR DOOR OPENER LIGHTING RIGHT REAR DOOR STORAGE ILLUMINATION RIGHT REAR DOOR WARNING LIGHT RIGHT REAR ENTRY LIGHT RIGHT REAR INTERIOR LOCK SWITCH RIGHT REAR OUTSIDE DOOR HANDLE ILLUMINATION RIGHT REAR WINDOW SWITCH
