Computer data lines circuit for Audi A8 D3 facelift (2005-2007)

BLK/BLU WIRE BRN WIRE DATA BUS ON BOARD DIAGNOSTIC INTERFACE (BEHIND GLOVE COMPARTMENT) DATA LINK CONNECTOR (UNDER LEFT SIDE OF DASH) DIGITAL SOUND SYSTEM CONTROL MODULE DISTANCE REGULATION CONTROL MODULE FRONT INFORMATION DISPLAY CONTROL HEAD FUSE 10 FUSE 12 FUSE 5 FUSE 7 FUSE 8 GRY/RED WIRE GRY/WHT WIRE HOT AT ALL TIMES HOT W/ VOLTAGE SUPPLY TERMINAL 15 RELAY ENERGIZED INSTRUMENT CLUSTER LEFT INSTRUMENT PANEL FUSE PANEL (BEHIND LEFT SIDE OF DASH) MEDIA PLAYER POSITION 2 MEDIA PLAYER, POSITION 1 NAVIGATION CONTROL UNIT W/ CD MECHANISM NCA WIRE ORG/BLK WIRE ORG/BRN WIRE ORG/GRN WIRE ORG/VIO WIRE RADIO RED/GRN WIRE RED/YEL WIRE RIGHT INSTRUMENT PANEL FUSE PANEL (BEHIND RIGHT SIDE OF DASH) SATELLITE RADIO SOUND SYSTEMS TV TUNER W/ BASE RADIO W/ PREMIUM RADIO WHT/YEL WIRE YEL WIRE

CENTRAL CONTROL MODULE (COMFORT SYSTEM) (IN LUGGAGE COMPT, BEHIND BATTERY) CLIMATRONIC CONTROL MODULE (FRONT OF CENTER CONSOLE) DISCONNECTION PLUG, RIGHT (CAN-BUS) ENERGY MANAGEMENT CONTROL MODULE (RIGHT SIDE OF LUGGAGE COMPT) ENGINE CONTROL MODULE (IN PASSENGER'S SIDE PLENUM CHAMBER E-BOX) ENGINE CONTROL MODULE 2 (6.0L) (IN PASSENGER'S SIDE PLENUM CHAMBER E-BOX) FRONT PASSENGER DOOR CONTROL MODULE (IN DOOR) GRY/WHT WIRE LEVEL CONTROL SYSTEM CONTROL MODULE (BEHIND GLOVE COMPARTMENT) ORG/BLK WIRE ORG/BRN WIRE ORG/GRN WIRE PASSENGER MEMORY SEAT CONTROL MODULE REAR MEMORY SEAT CONTROL MODULE RIGHT REAR DOOR CONTROL MODULE (IN DOOR) ROOF ELECTRONICS CONTROL MODULE (UNDER FRONT OF ROOF MODULE) TRANSMISSION CONTROL MODULE (IN MECHATRONICS UNIT, ON TRANSMISSION) VEHICLE ELECTRICAL SYSTEM CONTROL MODULE 2 (UNDER FRONT PASSENGER'S SEAT)

ABS CONTROL MODULE (LEFT SIDE OF ENGINE COMPT) ACCESS/ AIRBAG CONTROL MODULE (BELOW CENTER OF DASH) CONTROL MODULE (UNDER DRIVER'S SEAT) DISCONNECTION PLUG, LEFT (CAN-BUS) DRIVER DOOR CONTROL MODULE (IN DOOR) HEADLIGHT BEAM ADJUSTING CONTROL MODULE (BEHIND CLUSTER) LEFT REAR DOOR CONTROL MODULE (IN DOOR) MEMORY SEAT CONTROL MODULE ORG/BLK WIRE ORG/BRN WIRE ORG/GRN WIRE PARKING AID CONTROL MODULE (LEFT SIDE OF LUGGAGE COMPT) REAR A/C CONTROL HEAD STEERING COLUMN ELECTRONIC SYSTEMS CONTROL MODULE (ON STEERING COLUMN, TELEPHONE/ TELEMATIC CONTROL MODULE TIRE PRESSURE MONITORING CONTROL MODULE (UNDER LEFT SIDE OF REAR SEAT) TOWING RECOGNITION CONTROL MODULE VEHICLE ELECTRICAL SYSTEM CONTROL MODULE (BEHIND LEFT SIDE OF DASH)
