Audi A8 D3 facelift (2005-2007) solid state solid state Wiring diagram
This page shows the only wiring diagram for the component.solid state solid state, which is found in the car Audi A8 D3 facelift (2005-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram solid state solid state (1 of 1)
ACCESS/START CONTROL MODULE
AIR BAG CONTROL MODULE (BELOW CENTER OF DASH)
BLK WIRE
BLK/BLU WIRE
BLK/GRN WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
DRIVER'S FRONT AIR BAG CRASH SENSOR (LEFT FRONT OF ENGINE COMPT)
DRIVER'S SIDE SIDE AIR BAG CRASH SENSOR (AT LEFT "B" PILLAR)
FRONT/CENTER CONSOLE CONTROL HEAD
FUSE 18
FUSE 3
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
LEFT SEAT BELT SWITCH
LUGGAGE COMPARTMENT FUSE/RELAY PANEL
NCA WIRE
ORG/BLK WIRE
ORG/BRN WIRE
PASS SIDE AIR BAG OFF IND
PASSENGER'S FRONT AIR BAG CRASH SENSOR (RIGHT FRONT OF ENGINE COMPT)
PASSENGER'S SIDE SIDE AIR BAG CRASH SENSOR (AT RIGHT "B" PILLAR)
RED WIRE
RELAY & FUSE PANEL
RIGHT INSTRUMENT PANEL FUSE PANEL FUSE 9
RIGHT SEAT BELT SWITCH
SEAT OCCUPIED RECOGNITION CONTROL MODULE
SEAT OCCUPIED RECOGNITION PRESSURE SENSOR
SOLID STATE
SOLID STATE SOLID STATE
VOLTAGE SUPPLY TERMINAL 15 RELAY
WHT WIRE
YEL WIRE
Go to component: -> Supplemental restraints circuit (3 of 3) -> SOLID STATE SOLID STATE
