Audi A8 D3 facelift (2005-2007) rear passenger side occupied seat sensor Wiring diagram

BLK/BLU WIRE BLK/GRN WIRE BLU WIRE BLU/GRN WIRE BLU/YEL WIRE BRN WIRE BRN/GRY WIRE BRN/WHT WIRE CLIMATRONIC CONTROL MODULE CLIMATRONIC CONTROL MODULE (FRONT OF CENTER CONSOLE) COMPUTER DATA LINES SYSTEM FUSE 26 FUSE 33 FUSE 34 FUSE 9 GRN WIRE GRN/WHT WIRE GRN/YEL WIRE GRY WIRE GRY/BLU WIRE GRY/GRN WIRE GRY/VIO WIRE GRY/WHT WIRE GRY/YEL WIRE HOT AT ALL TIMES HOT WITH POWER SUPPLY RELAY 1 ENERGIZED HOT WITH VOLTAGE SUPPLY TERMINAL 15 RELAY ENERGIZED LEFT INSTRUMENT PANEL FUSE PANEL (BEHIND LEFT SIDE OF DASH) LEFT REAR AIR OUTLET MOTOR/POSITION SENSOR LEFT REAR CENTER CONSOLE TEMPERATURE SENSOR LEFT REAR FOOT WELL HEATER LEFT/RIGHT REAR HEATED SEAT TEMPERATURE SENSOR (W/O SEAT VENTILATION) LEFT/RIGHT SEAT VENTILATION CONTROL MODULE (IF EQUIPPED) ORG/BRN WIRE ORG/GRN WIRE REAR A/C CONTROL HEAD REAR DRIVER SIDE OCCUPIED SEAT SENSOR REAR PASSENGER SIDE OCCUPIED SEAT SENSOR RED/GRN WIRE RED/GRY WIRE RED/WHT WIRE RIGHT INSTRUMENT PANEL FUSE PANEL (BEHIND RIGHT SIDE OF DASH) RIGHT REAR AIR OUTLET MOTOR/POSITION SENSOR RIGHT REAR CENTER CONSOLE TEMPERATURE SENSOR RIGHT REAR FOOT WELL HEATER SEATS SYSTEM (W/ SEAT VENTILATION) VIO/BLU WIRE VIO/WHT WIRE W/ HEATED SEATS, W/O MEMORY
