Audi A8 D3 facelift (2005-2007) passenger's seat adjusting switch Wiring diagrams

BLU/YEL WIRE BRN WIRE BRN/GRY WIRE FUSE 41 GRN WIRE GRN/WHT WIRE GRY/BLU WIRE GRY/VIO WIRE HOT AT ALL TIMES LEFT REAR DOOR AMBIENT ILLUMINATION LEFT REAR DOOR AMBIENT LIGHTING VOLTAGE CONVERTER NCA WIRE PASSENGER'S SEAT ADJUSTING SWITCH RED/BLU WIRE RED/WHT WIRE RED/YEL WIRE RIGHT INSTRUMENT PANEL FUSE PANEL (BEHIND RIGHT SIDE OF DASH) RIGHT REAR ASHTRAY LIGHT RIGHT REAR DOOR CONTACT SWITCH RIGHT REAR DOOR OPENER LIGHTING RIGHT REAR DOOR STORAGE ILLUMINATION RIGHT REAR DOOR WARNING LIGHT RIGHT REAR ENTRY LIGHT RIGHT REAR INTERIOR LOCK SWITCH RIGHT REAR OUTSIDE DOOR HANDLE ILLUMINATION RIGHT REAR WINDOW SWITCH

AFT FORE/ BACK- REST BELT HEIGHT BLK/BLU WIRE BLK/RED WIRE BLK/WHT WIRE BLK/YEL WIRE BLU WIRE BLU/BLK WIRE BLU/BRN WIRE BLU/GRN WIRE BLU/WHT WIRE BLU/YEL WIRE BRN WIRE BRN/GRN WIRE COMPUTER DATA LINES SYSTEM DEPTH SEAT GRN WIRE GRN/BLK WIRE GRN/BLU WIRE GRN/BRN WIRE GRN/GRY WIRE GRN/VIO WIRE GRN/WHT WIRE GRN/YEL WIRE GRY/BLU WIRE GRY/GRN WIRE GRY/YEL WIRE HEAD BACKREST/ HEIGHT SEAT INCLIN- ATION LUMBAR FORE/ AFT LUMBAR HEIGHT LUMBAR/ BELT HEIGHT SWITCH MASSAGE ORG/BRN WIRE ORG/GRN WIRE PASSENGER MEMORY SEAT CONTROL MODULE PASSENGER'S SEAT ADJUSTING SWITCH PASSENGER'S SEAT BACKREST/ HEAD ADJUSTMENT MOTOR PASSENGER'S SEAT LUMBAR SUPPORT CURVATURE ADJUSTMENT MOTOR PASSENGER'S SEAT LUMBAR SUPPORT HEIGHT ADJUSTING MOTOR PASSENGER'S SEAT LUMBAR SUPPORT HEIGHT ADJUSTMENT MOTOR PASSENGER'S SEAT SWITCH RED WIRE RED/WHT WIRE RED/YEL WIRE REST HEAD- W/ MASSAGE W/ MASSAGE W/O MASSAGE W/O MASSAGE WHT WIRE WHT/BLK WIRE WHT/BLU WIRE WHT/RED WIRE WHT/VIO WIRE WHT/YEL WIRE YEL/GRY WIRE
