Audi A8 D3 facelift (2005-2007) passenger side door control module Wiring diagram
This page shows the only wiring diagram for the component.passenger side door control module, which is found in the car Audi A8 D3 facelift (2005-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram passenger side door control module (1 of 1)
AIR BAG CONTROL MODULE
ALARM HORN
BATTERY
BATTERY INTERRUPT IGNITER
BLK WIRE
BLU WIRE
BRN WIRE
CD CHANGER UNIT/ POSITION 1 MEDIA PLAYER
CIGARETTE LIGHTER
CIRCUIT BREAKER 46
CIRCUIT BREAKER 80
CLIMATRONIC CONTROL MODULE
COMMUN- ATION FUSE
COMPUTER DATA LINES SYSTEM
COOLANT FAN COOLANT FAN 2
ELECTRONIC PARKING BRAKE CONTROL MODULE COMFORT SYSTEM CENTRAL CONTROL MODULE
ENERGY MANAGEMENT CONTROL MODULE
FRONT INFORMATION DISPLAY CONTROL HEAD
FUEL PUMP RELAY
FUEL PUMP RELAY 2
FUSE 104 FUSE 42
FUSE 12 FUSE 39 FUSE 41
FUSE 130
FUSE 131
FUSE 132
FUSE 133
FUSE 15 FUSE 13 FUSE 14
FUSE 2 FUSE 26
FUSE 23 FUSE 11 FUSE 21
FUSE 24
FUSE 254
FUSE 34 FUSE 35
FUSE 36 FUSE 37 FUSE 43 FUSE 44 FUSE 27 FUSE 25
FUSE 37
FUSE 38
FUSE 6 FUSE 5 FUSE 7 FUSE 9
FUSE 8
GENERATOR
GRN WIRE
GRY WIRE
HEADLIGHT WASHER SYSTEM RELAY
HEATED FRONT WINDOW
INCLINATION/ ANTI-THEFT CONTROL MODULE
MAIN FUSE PANEL (BEHIND UPPER RIGHT KICK PANEL)
MOTOR
MOTRONIC ENGINE CONTROL MODULE POWER SUPPLY RELAY
MULTIMEDIA SIGNAL SPLITTER
NCA WIRE
ORG/ WIRE
PARKING BRAKE CONTACT SWITCH ENGINE CONTROL MODULE
PASSENGER MEMORY SEAT CONTROL MODULE
PASSENGER SIDE DOOR CONTROL MODULE
PASSENGER SIDE WINDOW REGULATOR CIRCUIT BREAKER
PLENUM CHAMBER E-BOX RELAY PANEL
POWER SEAT CIRCUIT BREAKER 1 (ON RELAY & FUSE PANEL, AT RIGHT KICK PANEL)
POWER SEAT CIRCUIT BREAKER 2 (ON RELAY & FUSE PANEL, AT RIGHT KICK PANEL)
RAIN/ LIGHT RECOGNITION SENSOR
REAR A/C CONTROL HEAD
REAR A/C CONTROL HEAD/ LEFT/RIGHT REAR SEAT VENTILATION CONTROL MODULE
REAR CIGARETTE LIGHTER
REAR POWER SEAT CIRCUIT BREAKER 2
REAR WINDOW DEFOGGER RELAY
RED WIRE
RED/BLU WIRE
RIGHT INSTRUMENT PANEL FUSE PANEL (BEHIND RIGHT SIDE OF DASH)
RIGHT LUGGAGE COMPARTMENT FUSE PANEL (RIGHT SIDE OF LUGGAGE COMPT)
RIGHT REAR DOOR CONTROL MODULE
RIGHT REAR SIDE BLIND CONTROL MODULE
ROOF ELECTRONICS CONTROL MODULE CD ROM DRIVER/ POSITION 2 MEDIA PLAYER
SECONDARY AIR INJECTION PUMP RELAY
SOCKET 3 SOCKET 2
TO LEFT INSTRUMENT PANEL FUSE PANEL (DIAGRAM
TO LEFT LUGGAGE COMPT FUSE PANEL (DIAGRAM
TRANSMISSION CONTROL MODULE
VIO WIRE
WHT WIRE
YEL WIRE
Go to component -> Power distribution circuit (1 of 3) -> PASSENGER SIDE DOOR CONTROL MODULE
