Audi A8 D3 facelift (2005-2007) left child safety switch Wiring diagram
This page shows the only wiring diagram for the component.left child safety switch, which is found in the car Audi A8 D3 facelift (2005-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left child safety switch (1 of 1)
BRN WIRE
COMPUTER DATA LINES SYSTEM
DRIVER WINDOW SWITCH
FRONT PASSENGER WINDOW SWITCH
FUSE 39
FUSE 41
GRY/BLU WIRE
HOT AT ALL TIMES
INTERIOR LIGHTS SYSTEM DOOR LOCKS SYSTEM
LEFT CHILD SAFETY SWITCH
LEFT FRONT WINDOW SWITCH
LEFT INSTRUMENT PANEL FUSE PANEL (BEHIND LEFT SIDE OF DASH)
LEFT REAR WINDOW SWITCH
ORG/BRN WIRE
ORG/GRN WIRE
RED/BLU WIRE
RED/YEL WIRE
RIGHT CHILD SAFETY SWITCH
RIGHT FRONT WINDOW SWITCH
RIGHT INSTRUMENT PANEL FUSE PANEL (BEHIND RIGHT SIDE OF DASH)
RIGHT REAR WINDOW SWITCH
WINDOW REGULATOR MOTOR
YEL/BLK WIRE
YEL/BLU WIRE
YEL/BRN WIRE
YEL/GRN WIRE
YEL/GRY WIRE
YEL/RED WIRE
YEL/WHT WIRE
Go to component -> Power windows circuit -> LEFT CHILD SAFETY SWITCH
