Audi A8 D3 facelift (2005-2007) heating element fold away motor Wiring diagram
This page shows the only wiring diagram for the component.heating element fold away motor, which is found in the car Audi A8 D3 facelift (2005-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram heating element fold away motor (1 of 1)
AUTO DAY/ NIGHT
BLK WIRE
BLK/GRN WIRE
BLK/GRY WIRE
BLK/YEL WIRE
BLU WIRE
BLU/BLK WIRE
BLU/GRY WIRE
BLU/RED WIRE
BLU/WHT WIRE
BRN WIRE
BRN/WHT WIRE
BRN/YEL WIRE
COMPUTER DATA LINES SYSTEM
DIRECTIONAL MOTORS, POSITION SWITCHES
DRIVER'S OUTSIDE MIRROR
ENTRY LAMP
FOLD AWAY MOTOR
FOLD AWAY SWITCH
FRONT PASSENGER'S OUTSIDE MIRROR
FUSE 39
GRY/BLU WIRE
GRY/WHT WIRE
GRY/YEL WIRE
HEATING ELEMENT
HEATING ELEMENT FOLD AWAY MOTOR
HOT AT ALL TIMES
INTERIOR LIGHTS SYSTEM DOOR LOCKS SYSTEM
LEFT INSTRUMENT PANEL FUSE PANEL (BEHIND LEFT SIDE OF DASH)
MIRROR ADJUSTMENT SWITCHES
MIRROR SELECTOR SWITCH
ORG/BRN WIRE
ORG/GRN WIRE
OUTSIDE MIRROR SWITCH
RED WIRE
RED/BLU WIRE
RIGHT INSTRUMENT PANEL FUSE PANEL (BEHIND RIGHT SIDE OF DASH) FUSE 39
WHT WIRE
WHT/YEL WIRE
Go to component: -> Memory mirrors circuit -> HEATING ELEMENT FOLD AWAY MOTOR
