Audi A8 D3 facelift (2005-2007) front passenger's seat ventilation control module Wiring diagram
This page shows the only wiring diagram for the component.front passenger's seat ventilation control module, which is found in the car Audi A8 D3 facelift (2005-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram front passenger's seat ventilation control module (1 of 1)
BLK WIRE
BLK/BLU WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU/GRN WIRE
BLU/WHT WIRE
BRN WIRE
BRN/BLK WIRE
BRN/BLU WIRE
BRN/YEL WIRE
CLIMATRONIC CONTROL MODULE (FRONT OF CENTER CONSOLE)
DRIVER'S SEAT BLOWER FAN
DRIVER'S SEAT HEATING ELEMENT, TEMPERATURE SENSOR
DRIVER'S SEAT SIDE BOLSTER HEATER
DRIVER'S SEAT VENTILATION CONTROL MODULE
DRIVER'S SEATBACK BLOWER FAN
DRIVER'S SEATBACK HEATING ELEMENT
DRIVER'S SEATBACK SIDE BOLSTER HEATER
FRONT PASSENGER'S SEAT OCCUPIED SENSOR
FRONT PASSENGER'S SEAT VENTILATION CONTROL MODULE
FUSE 20
FUSE 35
HOT AT ALL TIMES
HOT W/ POWER SUPPLY RELAY 1 ENERGIZED
PASSENGER'S SEAT BLOWER FAN
PASSENGER'S SEAT HEATING ELEMENT, TEMPERATURE SENSOR
PASSENGER'S SEAT SIDE BOLSTER HEATER
PASSENGER'S SEATBACK BLOWER FAN
PASSENGER'S SEATBACK HEATING ELEMENT
PASSENGER'S SEATBACK SIDE BOLSTER HEATER
RED WIRE
RED/WHT WIRE
RIGHT INSTRUMENT PANEL FUSE PANEL (BEHIND RIGHT SIDE OF DASH)
VIO WIRE
VIO/BLU WIRE
VIO/WHT WIRE
WHT WIRE
Go to component: -> Front seat heater circuit, with ventilation -> FRONT PASSENGER'S SEAT VENTILATION CONTROL MODULE
