Audi A8 D3 facelift (2005-2007) deck lid central locking system motor Wiring diagrams

This page contains all the electrical diagrams for the component. deck lid central locking system motor, in which he is found in the car Audi A8 D3 facelift (2005-2007). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram deck lid central locking system motor (1 of 2)

Wiring diagram deck lid central locking system motor for Audi A8 D3 facelift (2005-2007)

Get access

ALARM HORN BLK WIRE BRN WIRE COMFORT SYSTEM CENTRAL CONTROL MODULE (IN LUGGAGE COMPARTMENT, BEHIND BATTERY) COMPUTER DATA LINES SYSTEM DECK LID CENTRAL LOCKING SYSTEM MOTOR DOOR CLOSING CONTROL MODULE FRONT HOOD SWITCH FRONT HOOD SWITCH 2 FUEL TANK LID UNLOCK MOTOR TRUNK LOCK ALARM/CENTRAL LOCKING SWITCH FUSE 133 FUSE 31 FUSE 6 FUSE 7 FUSE 5 GRN WIRE GRN/WHT WIRE GRN/YEL WIRE HOT AT ALL TIMES INCLINATION/ ANTI-THEFT CONTROL MODULE (UNDER RIGHT SIDE OF REAR SEAT) LEFT INSTRUMENT PANEL FUSE PANEL (BEHIND LEFT SIDE OF DASH) ORG/BRN WIRE ORG/GRN WIRE REAR LID CLOSING ASSIST/ LOCK STOP SWITCH REAR LID CONTROL MODULE (RIGHT REAR OF LUGGAGE COMPT) REAR LID LOCK BUTTON (IN LUGGAGE COMPT) REAR LID LOCK CYLINDER UNLOCKING SWITCH REAR LID OPENING ASSIST UNLOCK STOP SWITCH RED WIRE RED/BLK WIRE RED/BLU WIRE RED/GRY WIRE RIGHT LUGGAGE COMPARTMENT FUSE PANEL (RIGHT SIDE OF LUGGAGE COMPT) TRUNK LID ALARM SWITCH VEHICLE ELECTRICAL SYSTEM CONTROL MODULE (BEHIND LEFT SIDE OF DASH) VIO WIRE VIO/WHT WIRE WHT WIRE WHT/BLK WIRE WHT/GRN WIRE WHT/RED WIRE WHT/VIO WIRE WHT/YEL WIRE YEL WIRE YEL/RED WIRE YEL/VIO WIRE YEL/WHT WIRE

Go to component: -> Anti-theft & central locking circuit (3 of 3) -> DECK LID CENTRAL LOCKING SYSTEM MOTOR

Wiring diagram deck lid central locking system motor (2 of 2)

Wiring diagram deck lid central locking system motor for Audi A8 D3 facelift (2005-2007)

Get access

ALARM HORN BLK WIRE BRN WIRE COMFORT SYSTEM CENTRAL CONTROL MODULE (IN LUGGAGE COMPARTMENT, BEHIND BATTERY) COMPUTER DATA LINES SYSTEM DECK LID CENTRAL LOCKING SYSTEM MOTOR DOOR CLOSING CONTROL MODULE FRONT HOOD SWITCH FRONT HOOD SWITCH 2 FUEL TANK LID UNLOCK MOTOR TRUNK LOCK ALARM/CENTRAL LOCKING SWITCH FUSE 133 FUSE 31 FUSE 6 FUSE 7 FUSE 5 GRN WIRE GRN/WHT WIRE GRN/YEL WIRE HOT AT ALL TIMES INCLINATION/ ANTI-THEFT CONTROL MODULE (UNDER RIGHT SIDE OF REAR SEAT) LEFT INSTRUMENT PANEL FUSE PANEL (BEHIND LEFT SIDE OF DASH) ORG/BRN WIRE ORG/GRN WIRE REAR LID CLOSING ASSIST/ LOCK STOP SWITCH REAR LID CONTROL MODULE (RIGHT REAR OF LUGGAGE COMPT) REAR LID LOCK BUTTON (IN LUGGAGE COMPT) REAR LID LOCK CYLINDER UNLOCKING SWITCH REAR LID OPENING ASSIST UNLOCK STOP SWITCH RED WIRE RED/BLK WIRE RED/BLU WIRE RED/GRY WIRE RIGHT LUGGAGE COMPARTMENT FUSE PANEL (RIGHT SIDE OF LUGGAGE COMPT) TRUNK LID ALARM SWITCH VEHICLE ELECTRICAL SYSTEM CONTROL MODULE (BEHIND LEFT SIDE OF DASH) VIO WIRE VIO/WHT WIRE WHT WIRE WHT/BLK WIRE WHT/GRN WIRE WHT/RED WIRE WHT/VIO WIRE WHT/YEL WIRE YEL WIRE YEL/RED WIRE YEL/VIO WIRE YEL/WHT WIRE

Go to component: -> Power door locks circuit (3 of 3) -> DECK LID CENTRAL LOCKING SYSTEM MOTOR
