Audi A8 D3 facelift (2005-2007) brn Wiring diagrams
This page contains all the electrical diagrams for the component. brn, in which he is found in the car Audi A8 D3 facelift (2005-2007). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram brn (91 of 102)
ACCESS/START CONTROL MODULE (UNDER DRIVER'S SEAT)
AIRBAG SPIRAL SPRING/ RETURN SPRING W/ SLIP RING
BLK WIRE
BLK/GRN WIRE
BLK/YEL WIRE
BLU WIRE
BRN WIRE
BRN/BLK WIRE
COMPUTER DATA LINES SYSTEM
DATA LINK CONNECTOR (UNDER LEFT SIDE OF DASH)
ENGINE CONTROL MODULE (4.2L, 6.0L) (IN PASSENGER'S SIDE PLENUM CHAMBER E-BOX)
ENGINE CONTROL MODULE 2 (6.0L) (IN PASSENGER'S SIDE PLENUM CHAMBER E-BOX)
FUSE 3
FUSE 32
FUSE 6 FUSE 9
GRN WIRE
GRY WIRE
GRY/WHT WIRE
GRY/YEL WIRE
HOT AT ALL TIMES
HOT W/ VOLTAGE SUPPLY TERMINAL 15 RELAY ENERGIZED
LEFT INSTRUMENT PANEL FUSE PANEL (BEHIND LEFT SIDE OF DASH)
MULTI- FUNCTION STEERING WHEEL CONTROL UNIT
NCA WIRE
ORG/BLK WIRE
ORG/BRN WIRE
ORG/GRN WIRE
RED WIRE
RED/YEL WIRE
RIGHT INSTRUMENT PANEL FUSE PANEL (BEHIND RIGHT SIDE OF DASH) FUSE 25
STEERING COLUMN ELECTRONICS SYSTEM CONTROL MODULE
STEERING WHEEL CONTROL UNIT
TIPTRONIC DOWNSHIFT BUTTON
TIPTRONIC SWITCH
TIPTRONIC UPSHIFT BUTTON
TRANSMISSION CONTROL MODULE (TCM) (IN MECHATRONICS UNIT, ON TRANSMISSION)
TRANSMISSION PARK SELECTOR SWITCH (W/ SHIFT LOCK SOLENOID)
YEL WIRE
YEL/BLU WIRE
YEL/GRN WIRE
Go to component: -> A/t circuit -> BRN WIRE
Wiring diagram brn (92 of 102)
BLK WIRE
BLU WIRE
BRN WIRE
BRN/BLK WIRE
BRN/BLU WIRE
BRN/GRN WIRE
BRN/GRY WIRE
BRN/WHT WIRE
BRN/YEL WIRE
CENTER MID/HIGH RANGE LOUDSPEAKER
DIGITAL SOUND SYSTEM CONTROL MODULE
FIBER OPTIC
FIBER OPTIC 10 11
FIBER OPTIC FIBER OPTIC
GRN WIRE
GRY WIRE
GRY/WHT WIRE
GRY/YEL WIRE
LEFT FRONT BASS, MIDRANGE SPEAKER
LEFT FRONT TREBLE SPEAKER, MOTOR
LEFT REAR MIDRANGE SPEAKER
LEFT REAR TREBLE SPEAKER
MICROPHONE UNIT
NCA WIRE
RED/BLK WIRE
RED/WHT WIRE
RIGHT FRONT BASS, MIDRANGE SPEAKER
RIGHT FRONT TREBLE SPEAKER, MOTOR
RIGHT REAR TREBLE SPEAKER
VIO/BLU WIRE
VIO/GRN WIRE
WHT WIRE
WHT/BLK WIRE
WHT/BLU WIRE
WHT/GRN WIRE
WHT/GRY WIRE
WHT/RED WIRE
WHT/YEL WIRE
YEL WIRE
Go to component: -> Multimedia interface circuit, premium radio (3 of 5) -> BRN WIRE
Wiring diagram brn (93 of 102)
AIRBAG CONTROL MODULE (BELOW CENTER OF DASH, ON TRANSMISSION TUNNEL)
BLK WIRE
BLK/BLU WIRE
BLK/WHT WIRE
BLU WIRE
BRN WIRE
CELLULAR TELEPHONE CONNECTOR
COMFORT SYSTEM CENTRAL CONTROL MODULE (IN LUGGAGE COMPT, BEHIND BATTERY)
COMPUTER DATA LINES SYSTEM
CRUISE CONTROL SYSTEM (W/ ADAPTIVE CRUISE CONTROL)
DATA BUS ON BOARD DIAGNOSTIC INTERFACE (BEHIND GLOVE BOX)
DATA LINK CONNECTOR (UNDER LEFT SIDE OF DASH)
FIBER OPTIC
FIBER OPTIC 4 5
FIBER OPTIC FIBER OPTIC
FUSE 10
FUSE 13
FUSE 20
GRN WIRE
GRY WIRE
GRY/RED WIRE
GRY/WHT WIRE
HOT AT ALL TIMES
HOT WITH POWER SUPPLY RELAY 1 ENERGIZED
HOT WITH VOLTAGE SUPPLY TERMINAL 15 RELAY ENERGIZED
INSTRUMENT CLUSTER
LEFT INSTRUMENT PANEL FUSE PANEL (BEHIND LEFT SIDE OF DASH) FUSE 5
NCA WIRE
ORG/BLK WIRE
ORG/BRN WIRE
ORG/GRN WIRE
ORG/VIO WIRE
PNK WIRE
RED WIRE
RED/BLK WIRE
RED/YEL WIRE
RIGHT INSTRUMENT PANEL FUSE PANEL (BEHIND RIGHT SIDE OF DASH)
TELEPHONE ANTENNA
TELEPHONE SUPPRESSION CHOKE
TELEPHONE/ TELEMATIC CONTROL MODULE
VIO WIRE
VIO/BLU WIRE
WHT WIRE
WHT/YEL WIRE
YEL WIRE
Go to component: -> Multimedia interface circuit, premium radio (5 of 5) -> BRN WIRE
Wiring diagram brn (94 of 102)
BLK WIRE
BLK/GRY WIRE
BLU WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
ELECTRIC PARK/ HANDBRAKE IND
ELECTRIC PARK/ HANDBRAKE MALFUNCTION IND
FUSE 1
FUSE 23
FUSE 8
FUSE 9
GRN WIRE
GRN/BLU WIRE
GRN/RED WIRE
GRN/VIO WIRE
GRN/WHT WIRE
GRY WIRE
GRY/BLK WIRE
GRY/BLU WIRE
GRY/BRN WIRE
GRY/GRN WIRE
GRY/RED WIRE
GRY/VIO WIRE
GRY/WHT WIRE
HOT AT ALL TIMES
INSTRUMENT CLUSTER
LEFT PARKING BRAKE MOTOR (AT LEFT REAR BRAKE CALIPER)
ORG/BLK WIRE
ORG/BRN WIRE
PARKING BRAKE CONTACT SWITCH
RED WIRE
RED/BLU WIRE
RED/GRN WIRE
RED/GRY WIRE
RIGHT INSTRUMENT PANEL FUSE PANEL (BEHIND RIGHT SIDE OF DASH)
RIGHT LUGGAGE COMPARTMENT FUSE PANEL (RIGHT SIDE OF LUGGAGE COMPARTMENT)
RIGHT PARKING BRAKE MOTOR (AT RIGHT REAR BRAKE CALIPER)
Go to component: -> Park brake release circuit -> BRN WIRE
Wiring diagram brn (95 of 102)
ACCESS/START CONTROL MODULE (UNDER DRIVER'S SEAT)
BLK WIRE
BLK/YEL WIRE
BLU WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
DATA LINK CONNECTOR (UNDER LEFT SIDE OF DASH)
ENGINE CONTROL MODULE (IN PASSENGER'S SIDE PLENUM CHAMBER E-BOX)
ENGINE CONTROL MODULE 2 (6.0L) (IN PASSENGER'S SIDE PLENUM CHAMBER E-BOX)
FUSE 32 FUSE 3
GRN WIRE
GRY WIRE
GRY/WHT WIRE
HOT AT ALL TIMES
HOT W/ VOLTAGE SUPPLY TERMINAL 15 RELAY ENERGIZED
ORG/BLK WIRE
ORG/BRN WIRE
RED WIRE
RED/YEL WIRE
RIGHT INSTRUMENT PANEL FUSE PANEL (BEHIND RIGHT SIDE OF DASH) FUSE 25
TRANSMISSION CONTROL MODULE (TCM) (IN MECHATRONICS UNIT, ON TRANSMISSION)
TRANSMISSION PARK SELECTOR SWITCH (W/ SHIFT LOCK SOLENOID)
YEL WIRE
Go to component: -> Shift interlock circuit -> BRN WIRE
Wiring diagram brn (96 of 102)
ACCESS/START CONTROL MODULE (UNDER DRIVER'S SEAT)
AIR BAG CONTROL MODULE
BATTERY
BATTERY INTERRUPT IGNITER
BLK WIRE
BLU WIRE
BLU/BLK WIRE
BRN WIRE
BRN/RED WIRE
CHARGING SYSTEM (GENERATOR)
ENGINE CONTROL MODULE (IN PASSENGER'S SIDE PLENUM CHAMBER E-BOX)
FUSE 3
GRN WIRE
MAIN FUSE PANEL (BEHIND UPPER RIGHT KICK PANEL)
POWER DISTRIBUTION SYSTEM
RED WIRE
RED/BLK WIRE
RIGHT LUGGAGE COMPARTMENT FUSE PANEL (RIGHT SIDE OF LUGGAGE COMPT)
STARTER
STARTER RELAY (ON RIGHT FRONT KICK PANEL RELAY PANEL)
STARTER RELAY 2 (ON RIGHT FRONT KICK PANEL RELAY PANEL)
VIO WIRE
VOLTAGE SUPPLY TERMINAL 15 RELAY (ON RELAY & FUSE PANEL, LEFT SIDE OF DASH)
WHT WIRE
Go to component: -> Starting circuit -> BRN WIRE
Wiring diagram brn (97 of 102)
ACCESS/START CONTROL MODULE (UNDER LEFT FRONT SEAT)
AIRBAG SPIRAL SPRING/ RETURN SPRING W/ SLIP RING
BLK WIRE
BLK/GRN WIRE
BLK/WHT WIRE
BLU WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
ENGINE CONTROL MODULE (ON PASSENGER'S SIDE PLENUM CHAMBER E-BOX)
FUSE 133
FUSE 6
FUSE 9
GRN WIRE
HOT AT ALL TIMES
LEFT INSTRUMENT PANEL FUSE PANEL (BEHIND LEFT SIDE OF DASH)
LEFT MULTI-FUNCTION BUTTONS
MULTI- FUNCTION STEERING WHEEL CONTROL UNIT
NCA WIRE
ORG/BLK WIRE
ORG/BRN WIRE
ORG/GRN WIRE
RED WIRE
RIGHT LUGGAGE COMPARTMENT FUSE PANEL (RIGHT SIDE OF LUGGAGE COMPT)
RIGHT MULTI-FUNCTION BUTTONS
STEERING COLUMN ELECTRONICS SYSTEM CONTROL MODULE
STEERING WHEEL CONTROL UNIT
YEL WIRE
Go to component: -> Steering wheel controls circuit -> BRN WIRE
Wiring diagram brn (98 of 102)
AIR BAG CONTROL MODULE (BELOW CENTER OF DASH)
BLK WIRE
BLK/YEL WIRE
BLU WIRE
BLU/RED WIRE
BRN WIRE
BRN/YEL WIRE
CENTER REAR SEAT BELT TENSIONER IGNITER
COMFORT SYSTEM CENTRAL CONTROL MODULE
DRIVER'S SEAT BELT TENSIONER IGNITER 1
DRIVER'S SIDE AIR BAG IGNITER
DRIVER'S SIDE HEAD AIR BAG IGNITER
GRN WIRE
GRY WIRE
GRY/RED WIRE
LEFT REAR AIR BAG IGNITER
LEFT REAR SEAT BELT TENSIONER IGNITER
PASSENGER'S SEAT BELT TENSIONER IGNITER 1
PASSENGER'S SIDE AIR BAG IGNITER
PASSENGER'S SIDE HEAD AIR BAG IGNITER
RED WIRE
RED/VIO WIRE
RIGHT REAR AIR BAG IGNITER
RIGHT REAR SEAT BELT TENSIONER IGNITER
SOLID STATE
TELEPHONE/ TELEMATIC CONTROL MODULE
VIO WIRE
VIO/BLU WIRE
WHT WIRE
WHT/BRN WIRE
YEL WIRE
Go to component: -> Supplemental restraints circuit (1 of 3) -> BRN WIRE
Wiring diagram brn (99 of 102)
AIR BAG SPIRAL SPRING/RETURN SPRING W/SLIP RING
BATTERY
BATTERY INTERRUPT IGNITER
BLK WIRE
BLK/YEL WIRE
BLU WIRE
BLU/RED WIRE
BRN WIRE
DRIVER'S KNEE AIR BAG IGNITER
DRIVER'S SIDE AIR BAG IGNITER 1
DRIVER'S SIDE AIR BAG IGNITER 2
GRY WIRE
GRY/RED WIRE
NCA WIRE
PASSENGER'S KNEE AIR BAG IGNITER
PASSENGER'S SIDE AIR BAG IGNITER 1 PASSENGER'S SIDE AIR BAG IGNITER 2
RED WIRE
RED/VIO WIRE
SHORTING CONTACT
STARTING/ CHARGING SYSTEM
VIO WIRE
WHT WIRE
WHT/BRN WIRE
YEL WIRE
Go to component: -> Supplemental restraints circuit (2 of 3) -> BRN WIRE
Wiring diagram brn (100 of 102)
ACCESS/START CONTROL MODULE
AIR BAG CONTROL MODULE (BELOW CENTER OF DASH)
BLK WIRE
BLK/BLU WIRE
BLK/GRN WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
DRIVER'S FRONT AIR BAG CRASH SENSOR (LEFT FRONT OF ENGINE COMPT)
DRIVER'S SIDE SIDE AIR BAG CRASH SENSOR (AT LEFT "B" PILLAR)
FRONT/CENTER CONSOLE CONTROL HEAD
FUSE 18
FUSE 3
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
LEFT SEAT BELT SWITCH
LUGGAGE COMPARTMENT FUSE/RELAY PANEL
NCA WIRE
ORG/BLK WIRE
ORG/BRN WIRE
PASS SIDE AIR BAG OFF IND
PASSENGER'S FRONT AIR BAG CRASH SENSOR (RIGHT FRONT OF ENGINE COMPT)
PASSENGER'S SIDE SIDE AIR BAG CRASH SENSOR (AT RIGHT "B" PILLAR)
RED WIRE
RELAY & FUSE PANEL
RIGHT INSTRUMENT PANEL FUSE PANEL FUSE 9
RIGHT SEAT BELT SWITCH
SEAT OCCUPIED RECOGNITION CONTROL MODULE
SEAT OCCUPIED RECOGNITION PRESSURE SENSOR
SOLID STATE
SOLID STATE SOLID STATE
VOLTAGE SUPPLY TERMINAL 15 RELAY
WHT WIRE
YEL WIRE
Go to component: -> Supplemental restraints circuit (3 of 3) -> BRN WIRE
