Audi A8 D3 facelift 2 (2007-2010) wht/gry Wiring diagrams

AIR FLOW FLAP MOTOR/ BACK PRESSURE FLAP MOTOR POSITION SENSOR BLK/GRN WIRE BLK/GRY WIRE BLK/RED WIRE BLK/VIO WIRE BLK/WHT WIRE BLK/YEL WIRE BRN/BLK WIRE BRN/BLU WIRE BRN/GRN WIRE BRN/WHT WIRE CLIMATRONIC CONTROL MODULE DEFROSTER FLAP MOTOR, POSITION SENSOR EVAPORATIVE VENT TEMPERATURE SENSOR FRESH AIR INTAKE DUCT TEMPERATURE SENSOR GRN WIRE GRN/BLK WIRE GRN/GRY WIRE GRN/RED WIRE GRN/VIO WIRE GRN/WHT WIRE GRY WIRE GRY/BLK WIRE GRY/BLU WIRE GRY/BRN WIRE GRY/GRN WIRE GRY/RED WIRE GRY/VIO WIRE GRY/WHT WIRE GRY/YEL WIRE LEFT FOOTWELL FLAP MOTOR/POSITION SENSOR LEFT FRONT DEFROST/ UPPER BODY SHUT OFF FLAP MOTOR/ POSITION SENSOR LEFT VENT TEMPERATURE SENSOR RECIRCULATION FLAP MOTOR, POSITION SENSOR RED WIRE RED/BLU WIRE RED/BRN WIRE RED/WHT WIRE RED/YEL WIRE RIGHT FOOTWELL FLAP MOTOR/POSITION SENSOR RIGHT FRONT DEFROST/ UPPER BODY SHUT OFF FLAP MOTOR/ POSITION SENSOR RIGHT VENT TEMPERATURE SENSOR TEMPERATURE REGULATOR FLAP MOTOR/POSITION SENSOR VIO WIRE VIO/BLK WIRE WHT WIRE WHT/BLK WIRE WHT/BRN WIRE WHT/GRY WIRE WHT/RED WIRE WHT/VIO WIRE WHT/YEL WIRE YEL WIRE YEL/BLK WIRE YEL/BLU WIRE YEL/GRY WIRE YEL/RED WIRE YEL/WHT WIRE

BLK WIRE BLU WIRE BRN WIRE BRN/BLK WIRE BRN/BLU WIRE BRN/GRN WIRE BRN/GRY WIRE BRN/WHT WIRE BRN/YEL WIRE CENTER MID/HIGH RANGE LOUDSPEAKER DIGITAL SOUND SYSTEM CONTROL MODULE (LEFT SIDE OF LUGGAGE COMPT) FIBER OPTIC FIBER OPTIC FIBER OPTIC FUSE 6 FUSE 10 GRN WIRE GRY WIRE HOT AT ALL TIMES LEFT FRONT BASS SPEAKER LEFT FRONT MIDRANGE SPEAKER LEFT LUGGAGE COMPARTMENT FUSE HOLDER (LEFT SIDE OF LUGGAGE COMPT) LEFT REAR MID/LOW RANGE LOUDSPEAKER LEFT REAR TREBLE SPEAKER MICROPHONE UNIT (W/ VOICE CONTROL) (IN FRONT ROOF MODULE) NAVIGATION ANTENNA (W/O TELEMATIC TELEPHONE) NAVIGATION W/ CD CONTROL MODULE (LEFT SIDE OF LUGGAGE COMPT) NCA WIRE REAR PARCEL SHELF LOUDSPEAKERS RED WIRE RED/BLK WIRE RED/BLU WIRE RED/GRN WIRE RED/GRY WIRE RED/WHT WIRE RED/YEL WIRE RIGHT FRONT BASS SPEAKER RIGHT FRONT MIDRANGE SPEAKER RIGHT REAR MID/LOW RANGE LOUDSPEAKER RIGHT REAR TREBLE SPEAKER SUBWOOFER VIO WIRE VIO/RED WIRE W/ TELEMATIC TELEPHONE W/ TELEPHONE W/O TELEMATIC TELEPHONE WHT WIRE WHT/BLK WIRE WHT/GRY WIRE WHT/YEL WIRE YEL WIRE

BLK WIRE BLK/WHT WIRE BLK/YEL WIRE BLU WIRE BLU/YEL WIRE BRN WIRE BRN/BLK WIRE BRN/BLU WIRE BRN/GRN WIRE BRN/GRY WIRE BRN/RED WIRE BRN/WHT WIRE BRN/YEL WIRE CENTER MID/HIGH RANGE LOUDSPEAKER DIGITAL SOUND SYSTEM CONTROL MODULE (LEFT SIDE OF LUGGAGE COMPT) FIBER OPTIC FIBER OPTIC FIBER OPTIC GRN WIRE GRN/YEL WIRE GRY WIRE GRY/WHT WIRE GRY/YEL WIRE LEFT FRONT BASS, MIDRANGE SPEAKER LEFT FRONT TREBLE SPEAKER, MOTOR LEFT REAR MIDRANGE SPEAKER LEFT REAR TREBLE SPEAKER MICROPHONE UNIT (W/ VOICE CONTROL) (IN FRONT OF ROOF MODULE) NCA WIRE RED/BLK WIRE RED/WHT WIRE RIGHT FRONT BASS, MIDRANGE SPEAKER RIGHT FRONT TREBLE SPEAKER, MOTOR RIGHT REAR MIDRANGE SPEAKER RIGHT REAR TREBLE SPEAKER VIO/BLU WIRE VIO/GRN WIRE W/ TELEPHONE WHT WIRE WHT/BLK WIRE WHT/BLU WIRE WHT/GRN WIRE WHT/GRY WIRE WHT/RED WIRE WHT/YEL WIRE YEL WIRE

ANTENNA (BEHIND CENTER REAR EDGE OF ROOF TRIM) BLK WIRE BLU WIRE BRN WIRE BRN/BLK WIRE BRN/BLU WIRE BRN/GRN WIRE BRN/GRY WIRE BRN/WHT WIRE BRN/YEL WIRE DIGITAL SOUND SYSTEM CONTROL MODULE (LEFT SIDE OF LUGGAGE COMPT) DIGITAL SOUND SYSTEM CONTROL MODULE 2 FIBER OPTIC GRN WIRE GRY WIRE GRY/WHT WIRE GRY/YEL WIRE LEFT REAR MID/LOW RANGE LOUDSPEAKER NAVIGATION ANTENNA (W/O TELEMATIC TELEPHONE) NAVIGATION W/ CD MECHANISM CONTROL UNIT NCA WIRE RED WIRE RED/BLK WIRE RED/BLU WIRE RED/GRN WIRE RED/WHT WIRE RIGHT REAR MID/LOW RANGE LOUDSPEAKER SUBWOOFER VIO/BLU WIRE VIO/GRN WIRE W/ TELELMATIC TELEPHONE W/O TELELMATIC TELEPHONE WHT WIRE WHT/BLK WIRE WHT/GRY WIRE WHT/RED WIRE WHT/YEL WIRE YEL WIRE

BLK WIRE BLK/BRN WIRE BLU WIRE BLU/BRN WIRE BLU/GRN WIRE BLU/GRY WIRE BLU/WHT WIRE BRN WIRE BRN/BLK WIRE BRN/GRN WIRE BRN/GRY WIRE BRN/RED WIRE BRN/VIO WIRE BRN/YEL WIRE ENGINE CONTROL MODULE (ECM) (IN PASSENGER'S SIDE PLENUM CHAMBER E-BOX) FUSE 29 FUSE 31 FUSE 30 FUSE 21 FUSE 40 FUSE 38 FUSE 5 FUSE 6 FUSE 7 FUSE 8 GRN WIRE GRN/RED WIRE GRN/VIO WIRE GRN/YEL WIRE GRY WIRE GRY/BLU WIRE GRY/VIO WIRE GRY/WHT WIRE KNOCK SENSOR 1 (INNER SIDE OF CYLINDER BANK 1) KNOCK SENSOR 2 (INNER SIDE OF CYLINDER BANK 1) KNOCK SENSOR 3 (INNER SIDE OF CYLINDER BANK 2) KNOCK SENSOR 4 (INNER SIDE OF CYLINDER BANK 2) NCA WIRE RED WIRE RED/BLK WIRE RED/BLU WIRE RED/GRN WIRE RED/GRY WIRE RED/VIO WIRE RED/WHT WIRE RED/YEL WIRE RIGHT INSTRUMENT PANEL FUSE HOLDER (IN RIGHT END OF DASH) TOP FRONT OF ENGINE FUEL PRESSURE SENSOR VIO WIRE WHT/BLK WIRE WHT/BLU WIRE WHT/BRN WIRE WHT/GRN WIRE WHT/GRY WIRE WHT/RED WIRE WHT/VIO WIRE WHT/YEL WIRE YEL WIRE YEL/BRN WIRE YEL/GRY WIRE

BLK WIRE BLK/BRN WIRE BLU WIRE BLU/BRN WIRE BLU/GRN WIRE BRN WIRE BRN/BLK WIRE BRN/GRN WIRE BRN/GRY WIRE BRN/RED WIRE BRN/VIO WIRE BRN/WHT WIRE COIL 2 COIL 3 COIL 4 COIL 5 COIL 6 COIL 7 COIL 8 E-BOX RELAY PANEL EVAPORATIVE EMISSION CANISTER PURGE REGULATOR VALVE FUSE 130 GRN WIRE GRN/RED WIRE GRN/VIO WIRE GRN/YEL WIRE GRY WIRE GRY/BLU WIRE GRY/VIO WIRE GRY/WHT WIRE NCA WIRE PLENUM CHAMBER) RED WIRE RED/BLK WIRE RED/BLU WIRE RED/GRN WIRE RED/GRY WIRE RED/VIO WIRE RED/YEL WIRE SECONDARY AIR INJECTION (AIR) PUMP RELAY TO SPARK PLUG WHT/BLK WIRE WHT/BLU WIRE WHT/BRN WIRE WHT/GRN WIRE WHT/GRY WIRE WHT/RED WIRE WHT/VIO WIRE WHT/YEL WIRE YEL WIRE YEL/BRN WIRE YEL/GRY WIRE YEL/VIO WIRE YEL/WHT WIRE

BLK WIRE BLK/BLU WIRE BLK/YEL WIRE BLU WIRE BLU/GRN WIRE BLU/RED WIRE BLU/WHT WIRE BRN WIRE BRN/GRN WIRE BRN/GRY WIRE BRN/VIO WIRE BRN/WHT WIRE CAMSHAFT ADJUSTMENT VALVE 1 FUEL INJECTORS (TOP OF CYLINDER BANK 1) FUEL PUMP (FP) RELAY (ON RIGHT KICK PANEL RELAY & FUSE PANEL) FUSE 28 FUSE 5 FUSE 29 FUSE 31 FUSE 7 FUSE 6 GRN WIRE GRN/RED WIRE GRN/YEL WIRE GRY WIRE GRY/BRN WIRE GRY/WHT WIRE HOT W/ VOLTAGE SUPPLY TERMINAL 15 RELAY ENERGIZED IGNITION COIL 1 IGNITION COIL 2 IGNITION COIL 3 IGNITION COIL 4 IGNITION COIL 5 IGNITION COIL 6 NCA WIRE PLUG PLUG SPARK RED WIRE RED/BLK WIRE RED/BLU WIRE RED/GRN BRN WIRE RED/GRN WIRE RED/GRY WIRE RED/WHT WIRE RED/YEL WIRE RIGHT INSTRUMENT PANEL FUSE HOLDER (IN RIGHT END OF DASH) SPARK SPARK PLUG TORQUE SUPPORT VALVE VIO WIRE VIO/GRN WIRE WHT WIRE WHT/BRN WIRE WHT/GRN WIRE WHT/GRY WIRE WHT/VIO WIRE WHT/YEL WIRE YEL WIRE YEL/BRN WIRE YEL/GRN WIRE YEL/RED WIRE

BLK WIRE BLK/BLU WIRE BLK/YEL WIRE BLU WIRE BLU/GRN WIRE BLU/RED WIRE BLU/WHT WIRE BRN WIRE BRN/GRN WIRE BRN/GRY WIRE BRN/VIO WIRE BRN/WHT WIRE GRN WIRE GRN/RED WIRE GRN/YEL WIRE GRY WIRE GRY/BLK WIRE GRY/BRN WIRE GRY/RED WIRE GRY/VIO WIRE GRY/WHT WIRE GRY/YEL WIRE IGNITION COILS NCA WIRE PLENUM CHAMBER E-BOX RELAY PANEL PLUG SPARK RED WIRE RED/BLU WIRE RED/GRN WIRE RED/GRY WIRE RED/WHT WIRE SECONDARY AIR INJECTION (AIR) PUMP RELAY 2 SECONDARY AIR INJECTION PUMP FUSE 2 SECONDARY AIR INJECTION PUMP MOTOR 2 (IN LOWER PART OF AIR) SPARK PLUG VIO WIRE VIO/GRN WIRE VIO/YEL WIRE WHT BRN WIRE WHT WIRE WHT/BRN WIRE WHT/GRN WIRE WHT/GRY WIRE WHT/VIO WIRE WHT/YEL WIRE YEL WIRE YEL/BRN WIRE YEL/GRN WIRE YEL/RED WIRE

BLK WIRE BLK/BLU WIRE BLK/YEL WIRE BLU WIRE BLU/GRN WIRE BLU/RED WIRE BLU/WHT WIRE BRN WIRE BRN/BLU WIRE BRN/GRN WIRE BRN/GRY WIRE BRN/VIO WIRE BRN/WHT WIRE ENGINE CONTROL MODULE (ECM) (IN PASSENGER'S SIDE PLENUM CHAMBER E-BOX) GRN WIRE GRN/BLU WIRE GRN/BRN WIRE GRN/GRY WIRE GRN/RED WIRE GRN/VIO WIRE GRN/YEL WIRE GRY WIRE GRY/BLK WIRE GRY/BLU WIRE GRY/BRN WIRE GRY/RED WIRE GRY/VIO WIRE GRY/WHT WIRE GRY/YEL WIRE INSTRUMENT CLUSTER CONTROL MODULE INSTRUMENT CLUSTER DISPLAY UNIT KNOCK SENSOR 3 KNOCK SENSOR 4 NCA WIRE ORG/BRN WIRE ORG/VIO WIRE RED WIRE RED/BLU WIRE RED/GRY WIRE RED/WHT WIRE VIO WIRE VIO/GRN WIRE VIO/YEL WIRE WHT WIRE WHT/BRN WIRE WHT/GRN WIRE WHT/GRY WIRE WHT/VIO WIRE WHT/YEL WIRE YEL WIRE YEL/BRN WIRE YEL/RED WIRE

BANK 1) BLK WIRE BLK/BLU WIRE BLK/WHT WIRE BLK/YEL WIRE BLU/GRN WIRE BLU/RED WIRE BLU/VIO WIRE BLU/WHT WIRE BLU/YEL WIRE BRN WIRE BRN/BLU WIRE BRN/GRN WIRE BRN/RED WIRE BRN/VIO WIRE BRN/WHT WIRE COOLING FANS SYSTEM ENGINE CONTROL MODULE (ECM) (IN PASSENGER'S SIDE PLENUM CHAMBER E-BOX) FUEL INJECTORS (TOP OF CYLINDER FUEL INJECTORS (TOP OF CYLINDER BANK 2) FUEL LEVEL SENDER FUEL LEVEL SENSOR 2 FUEL SUPPLY SENSOR 4 FUEL PUMP 2 RELAY FUSE 2 GRN WIRE GRN/BLU WIRE GRN/BRN WIRE GRN/GRY WIRE GRN/RED WIRE GRN/VIO WIRE GRN/YEL WIRE GRY WIRE GRY/BLK WIRE GRY/BLU WIRE GRY/BRN WIRE GRY/RED WIRE GRY/VIO WIRE GRY/WHT WIRE GRY/YEL WIRE HOT AT ALL TIMES KICK DOWN SWITCH (UNDER ACCELERATOR PEDAL) ORG/BRN WIRE ORG/VIO WIRE RED WIRE RED/GRY WIRE RED/WHT WIRE RIGHT LUGGAGE COMPARTMENT FUSE PANEL (RIGHT SIDE OF LUGGAGE COMPT) RIGHT LUGGAGE COMPARTMENT RELAY & FUSE HOLDER (RIGHT SIDE OF LUGGAGE COMPT) STARTING/ CHARGING SYSTEM TRANSFER FUEL FUEL PUMP, LEVEL FUEL LEVEL SENSOR 3 SENDER, FUEL LEVEL SENSOR 3 TRANSFER FUEL PUMP, FUEL LEVEL SENSOR 2, FUEL SUPPLY SENSOR 4 VIO WIRE VIO/GRN WIRE VIO/YEL WIRE WHT WIRE WHT/BRN WIRE WHT/GRN WIRE WHT/GRY WIRE WHT/VIO WIRE WHT/YEL WIRE YEL WIRE YEL/BRN WIRE YEL/RED WIRE
