Audi A8 D3 facelift 2 (2007-2010) w/ door closing assist Wiring diagrams

This page contains all the electrical diagrams for the component. w/ door closing assist, in which he is found in the car Audi A8 D3 facelift 2 (2007-2010). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

w/ door closing assist wiring diagram (1 of 4)

ALARM SYSTEM OFF SWITCH BLU WIRE BLU/WHT WIRE BRN WIRE BRN/GRY WIRE COMPUTER DATA LINES SYSTEM DRIVER SIDE INTERIOR LOCK SWITCH DRIVER'S DOOR CLOSING CONTROL MODULE (IF EQUIPPED) DRIVER'S DOOR HANDLE SWITCH DRIVER'S LOCK UNIT FOR CENTRAL LOCKING (IN DRIVER'S FRONT DOOR) FRONT PASSENGER'S INTERIOR LOCK SWITCH FRONT PASSENGER'S LOCK UNIT FOR CENTRAL LOCKING (IN PASSENGER'S FRONT DOOR) FUEL TANK LID REAR LID FUSE 13 FUSE 39 GRN/BLU WIRE GRN/YEL WIRE GRY WIRE GRY/BLU WIRE GRY/BRN WIRE GRY/RED WIRE GRY/VIO WIRE GRY/WHT WIRE GRY/YEL WIRE HOT AT ALL TIMES HOT AT ALL TIMES FRONT PASSENGER'S WINDOW REGULATOR FUSE HOT AT ALL TIMES LEFT INSTRUMENT FUSE PANEL FUSE HOLDER (IN LEFT END OF DASH) LOCK ORG/BRN WIRE ORG/GRN WIRE PASSENGER'S DOOR HANDLE SWITCH RADAR INTERIOR MONITORING CONTROL MODULE 1 REAR LID REMOTE CONTROL LOCK SWITCH/FUEL TANK LID UNLOCK BUTTON RED WIRE RED/BLK WIRE RED/BLU WIRE RED/YEL WIRE RIGHT INSTRUMENT PANEL FUSE HOLDER (IN RIGHT END OF DASH) ROOF ELECTRONICS CONTROL MODULE (UNDER FRONT OF ROOF MODULE) UNLOCK UNLOCK LOCK W/ DOOR CLOSING ASSIST YEL RED/ WIRE

Go to component -> Anti-theft & central locking circuit (1 of 3) -> W/ DOOR CLOSING ASSIST

w/ door closing assist wiring diagram (2 of 4)

BLU/WHT WIRE BRN GRN/BRN WIRE BRN WIRE BRN/GRY WIRE COMPUTER DATA LINES SYSTEM FUSE 41 GRN/BRN WIRE GRN/YEL WIRE GRY WIRE GRY/BLK WIRE GRY/BLU WIRE GRY/VIO WIRE GRY/WHT WIRE GRY/YEL WIRE HOT AT ALL TIMES HOT AT ALL TIMES LEFT INSTRUMENT FUSE PANEL FUSE HOLDER (IN LEFT END OF DASH) LEFT REAR DOOR HANDLE SWITCH LEFT REAR DOOR LOCK UNIT FOR CENTRAL LOCKING (IN LEFT REAR DOOR) LEFT REAR INTERIOR LOCK SWITCH ORG/BRN WIRE ORG/GRN WIRE POWER WINDOWS SYSTEM RED/BLK WIRE RED/BLU WIRE RED/YEL WIRE RIGHT INSTRUMENT PANEL FUSE HOLDER (IN RIGHT END OF DASH) RIGHT REAR DOOR HANDLE SWITCH RIGHT REAR DOOR LOCK UNIT FOR CENTRAL LOCKING (IN RIGHT REAR DOOR) RIGHT REAR INTERIOR SWITCH W/ CHILD SAFETY W/ DOOR CLOSING ASSIST

Go to component -> Anti-theft & central locking circuit (2 of 3) -> W/ DOOR CLOSING ASSIST
