Audi A8 D3 facelift 2 (2007-2010) right interior light roof electronics control module wiring diagram
This page shows the only wiring diagram for the component.right interior light roof electronics control module, which is found in the car Audi A8 D3 facelift 2 (2007-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
right interior light roof electronics control module wiring diagram (1 of 1)
AUTO
AUTOMATIC DAY/NIGHT INTERIOR MIRROR
BLU WIRE
BLU/BLK WIRE
BLU/BRN WIRE
BLU/GRN WIRE
BLU/GRY WIRE
BLU/RED WIRE
BLU/WHT WIRE
BLU/YEL WIRE
BRN WIRE
BRN/WHT WIRE
BRN/YEL WIRE
COMPUTER DATA LINES SYSTEM
DRIVER'S READING LIGHT BUTTON
FRONT INTERIOR LAMP BUTTON AUTO ON
FRONT PASSENGER'S READING LIGHT BUTTON
FUSE 13 PANEL FUSE HOLDER (IN RIGHT END OF DASH)
GRN WIRE
GRN/BLK WIRE
GRN/BLU WIRE
GRN/BRN WIRE
GRN/GRY WIRE
GRN/RED WIRE
GRN/WHT WIRE
GRN/YEL WIRE
HOT IN RUN OR START
HUMIDITY SENSOR
INTERIOR ILLUMINATION SWITCH
LEFT FRONT READING LIGHT
LEFT ILLUMINATED INTERIOR MAKE-UP MIRROR
LEFT INTERIOR LIGHT
LEFT MAKE-UP MIRROR LIGHT
LEFT MAKE-UP MIRROR LIGHT SWITCH
LEFT REAR INTERIOR LIGHT
LEFT REAR READING LIGHT
LEFT REAR READING LIGHT SWITCH
LEFT REAR WINDOW SHADE BUTTON
LIGHT RECOGNITION SENSOR
OFF
ORG/BRN WIRE
ORG/GRN WIRE
PASSENGER'S MAP/READING LIGHT
POWER TOPS SYSTEM
RADAR INTERIOR MONITORING CONTROL MODULE 1
REAR INTERIOR LAMP BUTTON
REAR ROOF MODULE CONTROL HEAD
REAR WINDOW SHADE SWITCH (REAR)
RED/YEL WIRE
RIGHT ILLUMINATED INTERIOR MAKE-UP MIRROR
RIGHT INSTRUMENT
RIGHT INTERIOR LIGHT ROOF ELECTRONICS CONTROL MODULE
RIGHT MAKE-UP MIRROR LIGHT
RIGHT REAR INTERIOR LIGHT
RIGHT REAR READING LIGHT
RIGHT REAR READING LIGHT SWITCH 1
RIGHT REAR WINDOW SHADE BUTTON
VIO/BLU WIRE
VIO/GRN WIRE
VIO/WHT WIRE
Go to component -> Interior lights circuit (3 of 7) -> RIGHT INTERIOR LIGHT ROOF ELECTRONICS CONTROL MODULE
