Audi A8 D3 facelift 2 (2007-2010) left rear foot well heater Wiring diagram

BLK/BLU WIRE BLK/GRN WIRE BLU WIRE BLU/GRN WIRE BLU/YEL WIRE BRN WIRE BRN/BLK WIRE BRN/GRY WIRE BRN/WHT WIRE CLIMATRONIC CONTROL MODULE COMPUTER DATA LINES SYSTEM FUSE 33 FUSE 34 FUSE 9 GRN WIRE GRN/WHT WIRE GRN/YEL WIRE GRY WIRE GRY/BLU WIRE GRY/GRN WIRE GRY/VIO WIRE GRY/WHT WIRE GRY/YEL WIRE HOT AT ALL TIMES HOT W/ POWER SUPPLY RELAY 1 TERMINAL 75 ENERGIZED HOT W/ VOLTAGE SUPPLY TERMINAL 15 RELAY ENERGIZED LEFT INSTRUMENT PANEL FUSE HOLDER (IN LEFT END OF DASH) LEFT REAR AIR OUTLET MOTOR/POSITION SENSOR LEFT REAR CENTER CONSOLE TEMPERATURE SENSOR (UNDER REAR OF CENTER CONSOLE) LEFT REAR FOOT WELL HEATER LEFT/RIGHT SEAT VENTILATION CONTROL MODULE ORG/BRN WIRE ORG/GRN WIRE REAR A/C CONTROL HEAD REAR DRIVER SIDE OCCUPIED SEAT SENSOR REAR PASSENGER SIDE OCCUPIED SEAT SENSOR RED/GRN WIRE RED/GRY WIRE RED/WHT WIRE RIGHT REAR AIR OUTLET MOTOR/POSITION SENSOR RIGHT REAR CENTER CONSOLE TEMPERATURE SENSOR (UNDER REAR OF CENTER CONSOLE) RIGHT REAR FOOT WELL HEATER SEATS SYSTEM SEATS SYSTEM (W/ SEAT VENTILATION) VIO/BLU WIRE VIO/WHT WIRE W/ HEATED SEATS, W/O MEMORY
