Audi A8 D3 facelift 2 (2007-2010) fuel lid unlock motor Wiring diagrams

ALARM HORN (RIGHT SIDE OF PLENUM CHAMBER) BLK WIRE BRN WIRE COMFORT SYSTEM CENTRAL CONTROL MODULE (RIGHT SIDE OF LUGGAGE COMPARTMENT) COMPUTER DATA LINES SYSTEM DECK LID CENTRAL LOCKING SYSTEM MOTOR (IN TRUNK LID) DOOR CLOSING CONTROL MODULE (RIGHT SIDE OF LUGGAGE COMPT, BEHIND BATTERY) FRONT HOOD SWITCH (IN LEFT HOOD LOCK ASSEMBLY) FRONT HOOD SWITCH 2 (IN RIGHT HOOD LOCK ASSEMBLY) FUEL LID UNLOCK MOTOR FUSE FUSE 6 FUSE 7 GRN/WHT WIRE GRN/YEL WIRE HOT AT ALL TIMES INCLINATION/ ANTI-THEFT CONTROL MODULE (UNDER RIGHT SIDE OF REAR SEAT) LEFT INSTRUMENT PANEL FUSE HOLDER (IN LEFT END OF DASH) ORG/BRN WIRE ORG/GRN WIRE REAR LID CLOSING ASSIST/ LOCK STOP SWITCH REAR LID CONTROL MODULE (RIGHT REAR OF LUGGAGE COMPT) REAR LID LOCK BUTTON REAR LID LOCK CYLINDER UNLOCKING BUTTON REAR LID OPENING ASSIST UNLOCK STOP SWITCH RED WIRE RED/BLK WIRE RED/BLU WIRE RED/GRY WIRE RIGHT LUGGAGE COMPT FUSE HOLDER (RIGHT SIDE OF LUGGAGE COMPT) TRUNK LID ALARM SWITCH TRUNK LID RELEASE MOTOR TRUNK LOCK ALARM/CENTRAL LOCKING SWITCH (INSIDE TRUNK LID) VEHICLE ELECTRICAL SYSTEM CONTROL MODULE (BEHIND LEFT SIDE OF DASH) VIO WIRE VIO/WHT WIRE WHT WIRE WHT/BLK WIRE WHT/GRN WIRE WHT/RED WIRE WHT/VIO WIRE WHT/YEL WIRE YEL WIRE YEL/RED WIRE YEL/VIO WIRE YEL/WHT WIRE

ALARM HORN (RIGHT SIDE OF PLENUM CHAMBER) BLK WIRE BRN WIRE COMFORT SYSTEM CENTRAL CONTROL MODULE (RIGHT SIDE OF LUGGAGE COMPARTMENT) COMPUTER DATA LINES SYSTEM DECK LID CENTRAL LOCKING SYSTEM MOTOR (IN TRUNK LID) DOOR CLOSING CONTROL MODULE (RIGHT SIDE OF LUGGAGE COMPT, BEHIND BATTERY) FRONT HOOD SWITCH (IN LEFT HOOD LOCK ASSEMBLY) FRONT HOOD SWITCH 2 (IN RIGHT HOOD LOCK ASSEMBLY) FUEL LID UNLOCK MOTOR FUSE FUSE 6 FUSE 7 GRN/WHT WIRE GRN/YEL WIRE HOT AT ALL TIMES INCLINATION/ ANTI-THEFT CONTROL MODULE (UNDER RIGHT SIDE OF REAR SEAT) LEFT INSTRUMENT PANEL FUSE HOLDER (IN LEFT END OF DASH) ORG/BRN WIRE ORG/GRN WIRE REAR LID CLOSING ASSIST/ LOCK STOP SWITCH REAR LID CONTROL MODULE (RIGHT REAR OF LUGGAGE COMPT) REAR LID LOCK BUTTON REAR LID LOCK CYLINDER UNLOCKING BUTTON REAR LID OPENING ASSIST UNLOCK STOP SWITCH RED WIRE RED/BLK WIRE RED/BLU WIRE RED/GRY WIRE RIGHT LUGGAGE COMPT FUSE HOLDER (RIGHT SIDE OF LUGGAGE COMPT) TRUNK LID ALARM SWITCH TRUNK LID RELEASE MOTOR TRUNK LOCK ALARM/CENTRAL LOCKING SWITCH (INSIDE TRUNK LID) VEHICLE ELECTRICAL SYSTEM CONTROL MODULE (BEHIND LEFT SIDE OF DASH) VIO WIRE VIO/WHT WIRE WHT WIRE WHT/BLK WIRE WHT/GRN WIRE WHT/RED WIRE WHT/VIO WIRE WHT/YEL WIRE YEL WIRE YEL/RED WIRE YEL/VIO WIRE YEL/WHT WIRE
