Audi A8 D3 facelift 2 (2007-2010) exterior mirror auto turn day/ signal night lamp Wiring diagram
This page shows the only wiring diagram for the component.exterior mirror auto turn day/ signal night lamp, which is found in the car Audi A8 D3 facelift 2 (2007-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram exterior mirror auto turn day/ signal night lamp (1 of 1)
ADJUSTMENT MOTORS FOLD, POSITION SWITCHES IN MOTOR
ADJUSTMENT MOTORS, POSITION SWITCHES
AUTO DAY/ EXTERIOR NIGHT MIRROR ENTRY TURN ELEMENT LAMP SIGNAL MOTOR LAMP
BLK WIRE
BLK/BLU WIRE
BLK/GRN WIRE
BLK/GRY WIRE
BLK/YEL WIRE
BLU WIRE
BLU/BLK WIRE
BLU/GRY WIRE
BLU/RED WIRE
BLU/YEL WIRE
BRN WIRE
BRN/BLU WIRE
BRN/YEL WIRE
COMPUTER DATA LINES SYSTEM
DRIVER DOOR CONTROL MODULE (INTEGRATED IN DRIVER'S DOOR WINDOW REGULATOR MOTOR)
DRIVER'S OUTSIDE MIRROR
ENTRY LAMP
EXTERIOR MIRROR AUTO TURN DAY/ SIGNAL NIGHT LAMP
FOLD AWAY SWITCH
FOLD HEATING IN
FRONT PASSENGER'S OUTSIDE MIRROR
FUSE 39
GRN/RED WIRE
GRY/BLU WIRE
GRY/WHT WIRE
GRY/YEL WIRE
HEATING ELEMENT
HOT AT ALL TIMES
INTERIOR LIGHTS SYSTEM, DOOR LOCKS SYSTEMS
LANE CHANGE ASSISTANCE CONTROL MODULE 2 (IF EQUIPPED)
LEFT INSTRUMENT PANEL FUSE HOLDER (IN LEFT END OF DASH)
MIRROR ADJUSTMENT SWITCHES
MIRROR SELECTOR SWITCH
ORG/BRN WIRE
ORG/GRN WIRE
OUTSIDE MIRROR SWITCH
PNK WIRE
RED WIRE
RED/BLU WIRE
RIGHT INSTRUMENT PANEL FUSE HOLDER (IN RIGHT END OF DASH) FUSE 39
VIO/BLU WIRE
WARNING LAMP
WHT WIRE
WHT/YEL WIRE
YEL WIRE
