Audi A8 D3 facelift 2 (2007-2010) driver's side door opener illumination Wiring diagram
This page shows the only wiring diagram for the component.driver's side door opener illumination, which is found in the car Audi A8 D3 facelift 2 (2007-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram driver's side door opener illumination (1 of 1)
ALARM SYSTEM OFF SWITCH
BLK WIRE
BLK/BLU WIRE
BLK/YEL WIRE
BLU/YEL WIRE
BRN WIRE
BRN/GRY WIRE
CENTRAL LOCKING SAFE IND LIGHT
DEFOGGER SYSTEM
DRIVER DOOR WARNING LIGHT
DRIVER INTERIOR LOCK SWITCH
DRIVER'S DOOR AMBIENT ILLUMINATION
DRIVER'S DOOR POWER WINDOW CONTROL HEAD
DRIVER'S DOOR STORAGE ILLUMINATION
DRIVER'S ENTRY LAMP (IN OUTSIDE MIRROR)
DRIVER'S SIDE DOOR CONTACT SWITCH
DRIVER'S SIDE DOOR OPENER ILLUMINATION
FUEL TANK LID UNLOCK/ REAR LID REMOTE CONTROL LOCK SWITCH
FUSE 39
GRN WIRE
GRN/WHT WIRE
GRY/BLU WIRE
GRY/VIO WIRE
GRY/WHT WIRE
HOT AT ALL TIMES
LEFT FRONT ENTRY LIGHT
LEFT FRONT OUTSIDE DOOR HANDLE ILLUMINATION
LEFT INSTRUMENT PANEL FUSE HOLDER (IN LEFT END OF DASH)
MIRROR ADJUSTMENT SWITCH
NCA WIRE
RED/BLU WIRE
RED/WHT WIRE
RED/YEL WIRE
YEL/BLU WIRE
YEL/WHT WIRE
Go to component -> Interior lights circuit (4 of 7) -> DRIVER'S SIDE DOOR OPENER ILLUMINATION
