Audi A8 D3 facelift 2 (2007-2010) cup holder illumination Wiring diagram

This page shows the only wiring diagram for the component.cup holder illumination, which is found in the car Audi A8 D3 facelift 2 (2007-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram cup holder illumination (1 of 1)

Wiring diagram cup holder illumination for Audi A8 D3 facelift 2 (2007-2010)

Get access

BRN WIRE CIGARETTE LIGHTER LIGHT COMBINATION PROCESSOR CUP HOLDER ILLUMINATION FOG LIGHT INDICATOR LIGHT FRONT/CENTER CONSOLE CONTROL HEAD FUSE GRY WIRE GRY/BLU WIRE GRY/YEL WIRE HEAD- LAMP SWITCH ILLUM- INATION HOT AT ALL TIMES INSTRUMENT CLUSTER LEFT CENTER ARMREST ILLUMINATION LEFT INSTRUMENT PANEL FUSE HOLDER (IN LEFT END OF DASH) LEFT REAR CENTER CONSOLE STORAGE ILLUMINATION LIGHT SWITCH NCA WIRE PARK LIGHT INDICATOR LIGHT REAR CENTER CONSOLE STORAGE ILLUMINATION REAR CIGARETTE LIGHTER LIGHT REAR WINDOW SHADE SWITCH RED/YEL WIRE RIGHT CENTER ARMREST ILLUMINATION RIGHT REAR CENTER CONSOLE STORAGE ILLUMINATION STORAGE COMPARTMENT ILLUMINATION

Go to component: -> Interior lights circuit (1 of 7) -> CUP HOLDER ILLUMINATION
