Audi A8 D3 facelift 2 (2007-2010) ation inclin- Wiring diagram
This page shows the only wiring diagram for the component.ation inclin-, which is found in the car Audi A8 D3 facelift 2 (2007-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram ation inclin- (1 of 1)
AFT FORE/
ATION INCLIN-
BLK/BRN WIRE
BLK/RED WIRE
BRN WIRE
FORE/ AFT
GRN/BLK WIRE
GRN/BLU WIRE
GRN/BRN WIRE
GRN/RED WIRE
GRN/VIO WIRE
GRN/WHT WIRE
GRN/YEL WIRE
GRY/BLK WIRE
GRY/BLU WIRE
GRY/BRN WIRE
GRY/RED WIRE
GRY/YEL WIRE
HEIGHT
INCLIN- ATION
MASSAGE
REAR MEMORY SEAT CONTROL MODULE
RED/GRY WIRE
RIGHT REAR SEAT FORE/AFT ADJUSTING MOTOR/SENSOR
RIGHT REAR SEAT LUMBAR SUPPORT FORE/AFT ADJUSTMENT MOTOR/SENSOR
RIGHT REAR SEAT LUMBAR SWITCH
RIGHT REAR SEAT SWITCH
RIGHT REAR SEAT TILT ADJUSTMENT MOTOR/SENSOR
UPPER BACKREST ADJUSTMENT MOTOR/SENSOR
VIO/GRN WIRE
VIO/RED WIRE
VIO/WHT WIRE
VIO/YEL WIRE
W/ LUMBAR MASSAGE W/O LUMBAR MASSAGE
WHT/GRN WIRE
YEL WIRE
YEL/BLU WIRE
YEL/BRN WIRE
YEL/RED WIRE
Go to component: -> Memory rear seat circuit (2 of 2) -> ATION INCLIN-
