Exterior lamps circuit, with drl for Audi A8 D3 (2002-2005)

BLK WIRE BLK/BLU WIRE BLK/GRN WIRE BLK/RED WIRE BLK/WHT WIRE BLU WIRE BRAKE/ TURN BRN WIRE EMERGENCY FLASHER RELAY (ON RELAY PANEL) FUSE FUSE 1 FUSE PANEL (RIGHT FRONT FOOTWELL) FUSE GRN WIRE GRY WIRE GRY/BLK WIRE GRY/RED WIRE GRY/WHT WIRE GRY/YEL WIRE HEADLIGHTS SYSTEM HIGH MOUNT BRAKE LIGHT HOT AT ALL TIMES IGNITION SWITCH LAMP CONTROL MODULE (ON RIGHT FRONT FOOTWELL E-BOX RELAY PANEL) LEFT LEFT FRONT SIDE TURN LIGHT LEFT FRONT TURN/ SIDE MARKER LIGHT LEFT HEADLAMP ASSEMBLY LEFT REAR SIDE MARKER LIGHT LEFT TAIL LIGHT LEFT TAILLAMP ASSEMBLY LIGHT SWITCH OFF OFF HEAD PARK RED WIRE RED/BLK WIRE RED/BLU WIRE RED/WHT WIRE RED/YEL WIRE RIGHT RUN WIRE TAIL TURN MARK WHT WIRE YEL WIRE YEL/BLK WIRE YEL/BRN WIRE YEL/GRN WIRE

AIRBAG CONTROL MODULE (BELOW LEFT SIDE OF DASH) BLK WIRE BLK/BLU WIRE BLK/GRN WIRE BLK/RED WIRE BLK/WHT WIRE BLU WIRE BRAKE LIGHT SWITCH (ABOVE PEDAL, ON BRACKET) BRAKE TAIL TURN BRAKE WARN BRN WIRE EMERGENCY FLASHER SWITCH FUSE FUSE PANEL (RIGHT FRONT FOOTWELL) GRN WIRE GRY WIRE GRY/RED WIRE GRY/WHT WIRE GRY/YEL WIRE HOT AT ALL TIMES HOT IN RUN OR START HOT W/ LOAD REDUCTION RELAY ENERGIZED INSTRUMENT CLUSTER LEFT TURN LICENSE PLATE LIGHTS MARK PARK RED WIRE RED/BLK WIRE RED/YEL WIRE RIGHT FRONT SIDE TURN LIGHT RIGHT FRONT TURN/ SIDE MARKER LIGHT RIGHT HEADLAMP ASSEMBLY RIGHT REAR SIDE MARKER LIGHT RIGHT TAIL LIGHT RIGHT TAILLAMP ASSEMBLY RIGHT TURN TELEPHONE/ TELEMATIC CONTROL MODULE (IF EQUIPPED) (FRONT OF LUGGAGE COMPT) TURN VIO WIRE WHT WIRE YEL WIRE
