Audi A8 D3 (2002-2005) passenger side airbag off indicator Wiring diagram
This page shows the only wiring diagram for the component.passenger side airbag off indicator, which is found in the car Audi A8 D3 (2002-2005). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram passenger side airbag off indicator (1 of 1)
A/C CLUTCH RELAY
A/C CONTROL HEAD
AIRBAG CONTROL MODULE
BLK WIRE
BLK/YEL WIRE
BLU WIRE
BRN WIRE
C.B. 37
C.B. 43
C.B. 44
C.B. 80
CENTRAL ELECTRIC PANEL
DRIVER'S, PASSENGER'S SIDE MIRROR
EMERGENCY FLASHER SWITCH
FROM CENTRAL ELECTRIC PANEL (DIAGRAM 2 OF 4)
FROM IGNITION SWITCH (DIAGRAM 1 OF 4) FRONT/REAR FOG LIGHT CONTROL MODULE
FUSE
FUSE 25
FUSE FUSE
FUSE FUSE FUSE
FUSE PANEL
GRN WIRE
GRY WIRE
LEFT FRONT POWER WINDOW CONTROL MODULE
LEFT REAR POWER WINDOW CONTROL MODULE
LEFT WASHER NOZZLE HEATER
MOTRONIC ENGINE CONTROL
MULTI-FUNCTION TRANSMISSION RANGE SWITCH
NAVIGATION CONTROL UNIT
PASSENGER SIDE AIRBAG OFF INDICATOR
PLENUM CHAMBER E-BOX RELAY & FUSE PANEL FUSE 116 FUSE 102 FUSE
REAR WINDOW DEFOGGER SWITCH
RED WIRE
RED/BLK WIRE
RIGHT FRONT FOOTWELL E-BOX AUXILIARY FUSE, RELAY PANEL
RIGHT FRONT POWER WINDOW CONTROL MODULE
RIGHT REAR POWER WINDOW CONTROL MODULE
RIGHT WASHER NOZZLE HEATER
SERVOTRONIC CONTROL MODULE
SOLAR CELL SEPARATION RELAY
SOLAR CELL SEPARATION RELAY (W/ SUNROOF)
STEERING COLUMN CONTROL UNIT
TELEPHONE TRANSCEIVER, RADIO
TELEPHONE/ TELEMATIC CONTROL MODULE
TO CENTRAL ELECTRIC PANEL (DIAGRAM 4 OF 4)
TRANSMISSION CONTROL MODULE
WHT WIRE
YEL WIRE
Go to component: -> Power distribution circuit (3 of 4) -> PASSENGER SIDE AIRBAG OFF INDICATOR
