Audi A8 D3 (2002-2005) motronic engine control module Wiring diagrams
This page contains all the electrical diagrams for the component. motronic engine control module, in which he is found in the car Audi A8 D3 (2002-2005). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram motronic engine control module (1 of 2)
ABS CONTROL MODULE (W/ STABILITY CONTROL)
ABS SOLENOID VALVE RELAY, ABS RETURN FLOW PUMP RELAY
BATTERY
BLK WIRE
BLK/BLU WIRE
BLK/RED WIRE
BLU WIRE
BRAKE LIGHT SWITCH
BRN WIRE
CENTRAL ELECTRIC PANEL
CIGARETTE LIGHTER
CONNECTOR
CONNECTOR FUSE 204
COOLANT PUMP, LEFT/RIGHT HEAT REGULATING VALVE
DATA LINK CONNECTOR
DAYTIME RUNNING LIGHTS SWITCH ON RELAY, FRONT/ REAR FOG LIGHT CONTROL MODULE
DAYTIME RUNNING LIGHTS SWITCH-ON RELAY
DUAL HORN RELAY
DUAL HORN RELAY 2
EMERGENCY FLASHER SWITCH
FUSE
FUSE 113
FUSE 119 FUSE 46 FUSE 123
FUSE 38 FUSE 92
FUSE 53
FUSE 54
FUSE FUSE
FUSE PANEL
FUSE PANEL FUSE
GRN WIRE
GRY WIRE
IGNITION SWITCH
KEY-IN IGNITION SWITCH
LOAD REDUCTION RELAY
LOW/HIGH TONE HORNS
MOTRONIC ENGINE CONTROL MODULE
MOTRONIC ENGINE CONTROL MODULE POWER SUPPLY RELAY
NAVIGATION CONTROL UNIT
OFF
PLENUM CHAMBER E-BOX RELAY & FUSE PANEL
RED WIRE
RED/WHT WIRE
RELAY & FUSE PANEL
RIGHT FOOTWELL E-BOX AUXILIARY FUSE, RELAY PANEL
RUN WIRE
STARTING INTERLOCK RELAY
STEERING ANGLE SENSOR
STEERING WHEEL CONTROL UNIT
TELEPHONE TRANSCEIVER, TELEPHONE/ TELEMATIC CONTROL MODULE
TO CENTRAL ELECTRIC PANEL (DIAGRAM 2 OF 4)
TO LIGHT SWITCH (DIAGRAM 2 OF 4)
TRANSMISSION CONTROL MODULE
VOLTAGE REGULATOR/ GENERATOR STARTER
WHT WIRE
WIPER/WASHER INTERMITTENT RELAY
YEL WIRE
YEL/BLK WIRE
Go to component -> Power distribution circuit (1 of 4) -> MOTRONIC ENGINE CONTROL MODULE
Wiring diagram motronic engine control module (2 of 2)
BLK WIRE
BLU WIRE
BRN WIRE
CENTRAL ELECTRIC PANEL
DAYTIME RUNNING LIGHTS SWITCH-ON RELAY
DTI
FOG LIGHT SWITCH, REAR FOG LIGHT SWITCH, FRONT/REAR FOG LIGHT CONTROL MODULE
FROM CENTRAL ELECTRIC PANEL (DIAGRAM 1 OF 4)
FROM IGNITION SWITCH (DIAGRAM 1 OF 4)
FRONT/REAR FOGLIGHT CONTROL MODULE
FUEL INJECTORS
FUEL PUMP
FUEL PUMP RELAY
FUSE
FUSE FUSE
FUSE PANEL
GRN WIRE
GRN/RED WIRE
GRY WIRE
HEADLIGHT BEAM ADJUSTMENT CONTROL MODULE, FRONT/REAR FOGLIGHT CONTROL MODULE
HEADLIGHT DIMMER/ FLASHER SWITCH
HEATED OXYGEN SENSORS, LEAK DETECTION PUMP
IGNITION COILS
LAMP CONTROL MODULE
LEFT HIGH BEAM HEADLIGHT, FRONT/REAR FOG LIGHT CONTROL MODULE
LIGHT LIGHT SWITCH SWITCH
MOTRONIC ENGINE CONTROL MODULE
PLENUM CHAMBER E-BOX RELAY & FUSE PANEL FUSE 117 FUSE 112
RED WIRE
RIGHT HIGH BEAM HEADLIGHT, INSTRUMENT CLUSTER
TO CENTRAL ELECTRIC PANEL (DIAGRAM 3 OF 4)
W/ DRL
W/ DRL W/O DRL
WHT WIRE
WIPER/ WASHER INTERMITTENT RELAY
YEL WIRE
Go to component -> Power distribution circuit (2 of 4) -> MOTRONIC ENGINE CONTROL MODULE
