Audi A8 D3 (2002-2005) left front bass speaker/ left front midrange speaker Wiring diagram

This page shows the only wiring diagram for the component.left front bass speaker/ left front midrange speaker, which is found in the car Audi A8 D3 (2002-2005). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram left front bass speaker/ left front midrange speaker (1 of 1)

Wiring diagram left front bass speaker/ left front midrange speaker for Audi A8 D3 (2002-2005)

Get access

AERIAL SELECTION CONTROL UNIT (AERIAL DIVERSITY FUNCTION) AMPLIFIER BLK WIRE BLK/WHT WIRE BLU/RED WIRE BRN WIRE GRN WIRE GRN/BLU WIRE GRN/BRN WIRE GRN/YEL WIRE GRY WIRE GRY/BLU WIRE GRY/BRN WIRE GRY/YEL WIRE LEFT FRONT BASS SPEAKER/ LEFT FRONT MIDRANGE SPEAKER LEFT REAR BASS SPEAKER LEFT REAR MIDRANGE SPEAKER NCA WIRE ORG/BRN WIRE ORG/VIO WIRE REAR WINDOW DEFOGGER WITH WINDOW ANTENNA RED/YEL WIRE RIGHT FRONT BASS SPEAKER/ RIGHT FRONT MIDRANGE SPEAKER RIGHT REAR BASS SPEAKER RIGHT REAR MIDRANGE SPEAKER TV ANTENNA AMPLIFIER 1 TV ANTENNA AMPLIFIER 2 TV ANTENNA AMPLIFIER 3 TV ANTENNA AMPLIFIER 4 WHT WIRE YEL WIRE

Go to component: -> Radio circuit (2 of 2) -> LEFT FRONT BASS SPEAKER/ LEFT FRONT MIDRANGE SPEAKER
