Audi A8 D3 (2002-2005) glove box lock switch Wiring diagrams

BLK/BLU WIRE BRN WIRE BRN/VIO WIRE BRN/WHT WIRE E-BOX RELAY PANEL ENTRY, FLOOR LIGHT RELAY FRONT INTERIOR LIGHT FUSE FUSE PANEL (AT RIGHT FRONT FOOT- WELL) GLOVE BOX COMPARTMENT LIGHT GLOVE BOX COMPARTMENT LIGHT SWITCH GLOVE BOX LOCK SWITCH GRN WIRE GRN/BLU WIRE GRY/BLU WIRE GRY/GRN WIRE HOT AT ALL TIMES HOT IN RUN AND START INTERIOR AND MAP READING LIGHT RELAY (ON RELAY PANEL) LEFT FRONT MAKE- UP MIRROR LIGHT LEFT FRONT MAKE-UP MIRROR LIGHT SWITCH LEFT LUGGAGE COMPARTMENT LIGHT LEFT REAR ASHTRAY LIGHT LEFT REAR HEATED SEAT REGULATING SWITCH LEFT REAR MAKE- UP MIRROR LIGHT LEFT REAR MAKE-UP MIRROR LIGHT SWITCH (ABOVE RIGHT KICK PANEL) LUGGAGE COMPARTMENT LIGHT MIRRORS SYSTEM NCA WIRE REAR CIGARETTE LIGHTER REAR HEADREST ADJUST SWITCH REAR READING/COURTESY LIGHT RED WIRE RED/BLK WIRE RED/BLU WIRE RED/GRN WIRE RED/GRY WIRE RED/YEL WIRE RIGHT FRONT MAKE- UP MIRROR LIGHT RIGHT FRONT MAKE-UP MIRROR LIGHT SWITCH RIGHT REAR ASHTRAY LIGHT RIGHT REAR HEATED SEAT REGULATING SWITCH RIGHT REAR MAKE- UP MIRROR LIGHT RIGHT REAR MAKE-UP MIRROR LIGHT SWITCH STORAGE COMPARTMENT ILLUMINATION

BLK WIRE BLU WIRE BRN WIRE BRN/BLK WIRE DECKLID CENTRAL LOCKING SYSTEM MOTOR FUSE FUSE PANEL GLOVE BOX LOCK SWITCH GRY WIRE HOT AT ALL TIMES INTERIOR MONITORING SENSORS CONTROL MODULE (LEFT SIDE OF LUGGAGE COMPT) LUGAGGE COMPARTMENT LID RELEASE SWITCH RED/BLK WIRE RED/BRN WIRE RED/YEL WIRE
