Audi A8 D3 (2002-2005) decklid central locking system motor Wiring diagram

This page shows the only wiring diagram for the component.decklid central locking system motor, which is found in the car Audi A8 D3 (2002-2005). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram decklid central locking system motor (1 of 1)

Wiring diagram decklid central locking system motor for Audi A8 D3 (2002-2005)

Get access

BLK WIRE BLU WIRE BRN WIRE BRN/BLK WIRE DECKLID CENTRAL LOCKING SYSTEM MOTOR FUSE FUSE PANEL GLOVE BOX LOCK SWITCH GRY WIRE HOT AT ALL TIMES INTERIOR MONITORING SENSORS CONTROL MODULE (LEFT SIDE OF LUGGAGE COMPT) LUGAGGE COMPARTMENT LID RELEASE SWITCH RED/BLK WIRE RED/BRN WIRE RED/YEL WIRE

Go to component: -> Trunk release circuit -> DECKLID CENTRAL LOCKING SYSTEM MOTOR
