Audi A8 D2 (1994-1999) fog light switch Wiring diagrams

This page contains all the electrical diagrams for the component. fog light switch, in which he is found in the car Audi A8 D2 (1994-1999). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram fog light switch (1 of 2)

Wiring diagram fog light switch for Audi A8 D2 (1994-1999)

Get access

ALARM SYSTEM INDICATOR ANTI-THEFT SYSTEM BATTERY BLK WIRE BLK/BLU WIRE BLU WIRE BLU/GRN WIRE BRN WIRE BRN/YEL WIRE DAYTIME RUNNING LIGHTS CHANGE-OVER RELAY (ON RIGHT FOOTWELL E-BOX) DAYTIME RUNNING LIGHTS SWITCH-ON RELAY (ON RIGHT FOOTWELL E-BOX) FOG LAMP HIGH BEAM FOG LIGHT RELAY (ON RIGHT FRONT FOOTWELL E-BOX AUXILIARY FUSE, RELAY PANEL) FOG LIGHT SWITCH FRONT, REAR FOG LIGHT SWITCH FUSE FUSE FUSE FUSE FUSE FUSE FUSE PANEL (RIGHT FRONT FOOT- WELL) GRN WIRE GRN/BLK WIRE GRN/GRN WIRE GRN/RED WIRE GRN/WHT WIRE GRY WIRE GRY/BLU WIRE GRY/WHT WIRE HEAD HEADLAMP DIMMER SWITCH HIGH BEAM FOG LAMP LOW BEAM HIGH BEAM INDICATOR HOT IN RUN OR START HOT W/ LOAD REDUCTION RELAY ENERGIZED IGNITION SWITCH ILLUM INSTRUMENT CLUSTER INSTRUMENT CLUSTER SYSTEM LAMP CONTROL MODULE (ON RIGHT FRONT FOOTWELL E-BOX RELAY PANEL) LEFT HEADLAMP ASSEMBLY LEFT REAR FOG LIGHT LIGHT SWITCH LOW BEAM LOW BEAM/ REAR LIGHT INDICATOR NCA WIRE OFF OFF HEAD PARK OFF PARK PARK RED WIRE RED/BLU WIRE RIGHT HEADLAMP ASSEMBLY RUN WIRE SERIES RESISTANCE WIRING WHT WIRE WHT/BLU WIRE WHT/YEL WIRE YEL WIRE YEL/BLK WIRE YEL/BRN WIRE YEL/GRN WIRE

Go to component: -> Headlamps & fog lamps circuit, with drl -> FOG LIGHT SWITCH

Wiring diagram fog light switch (2 of 2)

Wiring diagram fog light switch for Audi A8 D2 (1994-1999)

Get access

1998-99 ALARM SYSTEM INDICATOR ANTI-THEFT SYSTEM BATTERY BLK WIRE BLK/BLU WIRE BLU WIRE BRN WIRE BRN/YEL WIRE FOG LAMP HIGH BEAM FOG LIGHT RELAY (ON RIGHT FRONT FOOTWELL E-BOX AUXILIARY FUSE, RELAY PANEL) FOG LIGHT SWITCH FRONT, REAR FOG LIGHT SWITCH FUSE FUSE FUSE FUSE PANEL (RIGHT FRONT FOOTWELL) FUSE GRN WIRE GRN/BLK WIRE GRN/GRN WIRE GRN/RED WIRE GRY WIRE GRY/BLU WIRE GRY/WHT WIRE HEAD HEADLAMP DIMMER SWITCH HIGH BEAM FOG LAMP LOW BEAM HIGH BEAM INDICATOR HOT IN RUN OR START IGNITION SWITCH ILLUM INSTRUMENT CLUSTER INSTRUMENT CLUSTER SYSTEM LAMP CONTROL MODULE (ON RIGHT FRONT FOOTWELL E-BOX RELAY PANEL) LEFT HEADLAMP ASSEMBLY LEFT REAR FOG LIGHT LIGHT SWITCH LOW BEAM LOW BEAM/ REAR LIGHT INDICATOR OFF OFF HEAD PARK OFF PARK POWER DISTRIBUTION SYSTEM (LOAD REDUCTION RELAY) RED WIRE RED/BLU WIRE RIGHT HEADLAMP ASSEMBLY RUN WIRE WHT WIRE WHT/YEL WIRE YEL WIRE YEL/BLK WIRE YEL/BRN WIRE YEL/GRN WIRE

Go to component: -> Headlamps & fog lamps circuit, without drl -> FOG LIGHT SWITCH
