Audi A8 D2 (1994-1999) driver's seat adjustment switch wiring diagram
This page shows the only wiring diagram for the component.driver's seat adjustment switch, which is found in the car Audi A8 D2 (1994-1999). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
driver's seat adjustment switch wiring diagram (1 of 1)
BACK- REST
BLK WIRE
BLK/BLU WIRE
BLU WIRE
BRN WIRE
BRN/GRN WIRE
CIRCUIT BREAKER 44
DRIVER'S SEAT ADJUSTMENT SWITCH
FORE/ AFT
FRONT HEIGHT
FUSE
FUSE PANEL (AT RIGHT FRONT FOOTWELL)
GRN WIRE
GRN/YEL WIRE
HEAD- REST
HOT AT ALL TIMES
HOT W/ LOAD REDUCTION RELAY ENERGIZED
MEMORY PROGRAM SWITCH
REAR HEIGHT
RED WIRE
RED/BLU WIRE
RED/GRN WIRE
RED/WHT WIRE
RIGHT FRONT FOOTWELL E-BOX AUXILIARY FUSE, RELAY PANEL
VIO/BLK WIRE
WHT WIRE
WHT/BLK WIRE
WHT/GRN WIRE
YEL WIRE
YEL/BLU WIRE
YEL/GRN WIRE
YEL/RED WIRE
Go to component -> Driver"s memory seat circuit (2 of 2) -> DRIVER'S SEAT ADJUSTMENT SWITCH
