Navigation circuit, w/ amplifier & bang & olufsen sound for Audi A7 II (2018-2023)

BLK WIRE BOTTOM COUPLING POINT ON LEFT A-PILLAR BOTTOM COUPLING POINT ON RIGHT A-PILLAR BRN WIRE BRN/BLU WIRE BRN/GRN WIRE BRN/GRY WIRE BRN/VIO WIRE BRN/YEL WIRE DIGITAL SOUND SYSTEM CONTROL MODULE DIGITAL SOUND SYSTEM FUSE GRN WIRE GRN/BLK WIRE GRY WIRE GRY/BLK WIRE GRY/BLU WIRE GRY/GRN WIRE HOT AT ALL TIMES LEFT FRONT BASS SPEAKER LEFT FRONT DOOR COUPLING POINT LEFT FRONT DOOR SPEAKER LEFT FRONT MIDRANGE SPEAKER LEFT FRONT TREBLE SPEAKER LEFT FRONT TREBLE SPEAKER, MOTOR LEFT REAR BASS SPEAKER LEFT REAR DOOR COUPLING POINT MOST DATA BUS CIRCUIT RED/BLU WIRE RED/GRN WIRE RED/GRY WIRE RED/YEL WIRE RELAY & FUSE PANEL 4 RIGHT FRONT BASS SPEAKER RIGHT FRONT DOOR COUPLING POINT RIGHT FRONT DOOR SPEAKER RIGHT FRONT MIDRANGE SPEAKER RIGHT FRONT TREBLE SPEAKER RIGHT FRONT TREBLE SPEAKER, MOTOR RIGHT REAR BASS SPEAKER RIGHT REAR DOOR COUPLING POINT SOUND SYSTEMS VIO WIRE VIO/BLU WIRE VIO/GRN WIRE WHT WIRE WHT/BLU WIRE WHT/YEL WIRE

BLK WIRE BLK/WHT WIRE BLU/WHT WIRE BLU/YEL WIRE BRN/BLU WIRE BRN/GRN WIRE BRN/YEL WIRE COUPLING POINT IN LEFT REAR DOOR COUPLING POINT IN RIGHT REAR DOOR DIGITAL SOUND SYSTEM CONTROL MODULE (LEFT REAR OF LUGGAGE COMPT) GRN WIRE GRN/BLK WIRE GRN/RED WIRE GRN/VIO WIRE GRN/WHT WIRE GRY WIRE GRY/BLK WIRE LEFT EFFECTS SPEAKER LEFT REAR DOOR COUPLING POINT LEFT REAR MIDRANGE SPEAKER 2 LEFT REAR TREBLE SPEAKER MOST DATA BUS CIRCUIT RED/BLU WIRE RED/GRN WIRE RED/YEL WIRE RIGHT REAR DOOR COUPLING POINT RIGHT REAR MIDRANGE SPEAKER 2 RIGHT REAR TREBLE SPEAKER SOUND SYSTEMS VIO WIRE VIO/BLK WIRE WHT WIRE WHT/BLK WIRE WHT/BLU WIRE WHT/YEL WIRE

ANTENNA ANTENNA AMPLIFIER (RIGHT "C" PILLAR) BLK WIRE BLK/GRY WIRE BLU/GRY WIRE BLU/YEL WIRE BOTTOM COUPLING POINT ON LEFT A-PILLAR BRN WIRE BRN/GRN WIRE CELLULAR TELEPHONE AMPLIFIER CENTER COUPLING POINT ON INSTRUMENT PANEL CENTER SPEAKER CENTER SPEAKER 2 COMPUTER DATA LINES SYSTEM DRIVER VOLUME CONTROL FUSE 6 FUSE PANEL F GRN/RED WIRE GRN/VIO WIRE GRN/WHT WIRE HOT AT ALL TIMES INFORMATION ELECTRONICS CONTROL MODULE 1 (RIGHT SIDE OF DASH) LEFT FRONT MIDRANGE SPEAKER 2 MOST DATA BUS CIRCUIT NCA WIRE ORG/BRN WIRE RED WIRE RED/BLU WIRE RED/GRN WIRE RIGHT EFFECTS SPEAKER RIGHT FRONT MIDRANGE SPEAKER 2 SOUND SYSTEMS VIO WIRE VIO/BLK WIRE W/ SATELLITE RADIO W/ TV TUNER, DIGITAL RADIO WHT WIRE WHT/BLK WIRE WHT/BLU WIRE WHT/GRN WIRE

ANTENNA AMPLIFIER 2 (LEFT "C" PILLAR) AUXILIARY DISPLAY CONTROL HEAD 1 BLK WIRE BLU WIRE BLU/GRN WIRE BOTTOM COUPLING POINT ON RIGHT A-PILLAR BRN WIRE COMPUTER DATA LINES SYSTEM DIGITAL RADIO ANTENNA FUSE 2 FUSE 5 FUSE PANEL M GPS ANTENNA GRY WIRE HOT AT ALL TIMES INFORMATION ELECTRONICS CONTROL MODULE 1 (RIGHT SIDE OF DASH) LTE ANTENNA 1 NAVIGATION SYSTEM NCA WIRE ORG/BRN WIRE RADIO ANTENNA 2 RED WIRE RED/BLK WIRE RED/VIO WIRE RED/YEL WIRE ROOF ANTENNA ROOF ANTENNA CONTROL MODULE SATELLITE ANTENNA W/ DIGITAL RADIO W/ EMERGENCY CALL MODULE W/ SATELLITE RADIO W/ VEHICLE POSITIONING SYSTEM W/O DIGITAL RADIO W/O EMERGENCY CALL MODULE W/O VEHICLE POSITIONING SYSTEM WHT WIRE WIRELESS CONTROL HEAD 1

BLK WIRE BLU WIRE BLU/GRN WIRE BOTTOM COUPLING POINT ON LEFT A-PILLAR BOTTOM COUPLING POINT ON RIGHT A-PILLAR BRN WIRE FRONT ROOF MODULE MICROPHONE UNIT GRN WIRE GRY/GRN WIRE INTERIOR MICROPHONE LEFT FRONT MICROPHONE NAVIGATION SYSTEM NCA WIRE ORG/ WIRE RED/BLK WIRE RED/YEL WIRE RIGHT FRONT MICROPHONE USB CONNECTION 1 USB DISTRIBUTOR W/ EXTERNAL AUDIO SOURCE CONNECTION AUDIO MUSIC INTERFACE WHT WIRE YEL/GRN WIRE

BLK WIRE BLU WIRE BRN WIRE COMPUTER DATA LINES SYSTEM FRONT INFORMATION DISPLAY CONTROL HEAD FRONT INFORMATION DISPLAY CONTROL HEAD 2 FUSE 2 FUSE 3 FUSE 8 FUSE PANEL F FUSE PANEL G GRN WIRE HOT AT ALL TIMES NCA WIRE ORG/ WIRE ORG/BRN WIRE RED WIRE RED/BLK WIRE RED/WHT WIRE RED/YEL WIRE STANDARD, MEDIUM W/ EXTERNAL AUDIO SOURCE CONNECTION AUDIO MUSIC INTERFACE

BLK WIRE BLU WIRE BOTTOM COUPLING POINT ON LEFT A-PILLAR BOTTOM COUPLING POINT ON RIGHT A-PILLAR BRN WIRE COMPUTER DATA LINES SYSTEM DATA BUS ON BOARD DIAGNOSTIC INTERFACE DVD PLAYER GRN WIRE GRY/BLU WIRE INFORMATION ELECTRONICS CONTROL MODULE 1 INSTRUMENT CLUSTER CONTROL MODULE LTE ANTENNA 1 LTE ANTENNA 2 MOST DATA BUS CIRCUIT NAVIGATION SYSTEM NAVIGATION SYSTEM (EMERGENCY CALL CIRCUIT) NAVIGATION SYSTEM (REAR CAMERA CIRCUIT) NCA WIRE ORG/ WIRE ORG/BRN WIRE PNK WIRE REAR CAMERA CIRCUIT RED/WHT WIRE SOUND SYSTEMS VEHICLE INTERIOR COMMUNICATION ANTENNA VIO/GRY WIRE W/ EMERGENCY CALL MODULE W/ MOBILE ONLINE SERVICES WHT WIRE
